Rockland Colloid - Should I bother?

Discussion in 'Alternative Processes' started by bvy, Mar 23, 2014.

  1. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    .

    thanks don !
    when i originally was experimenting with subbing plates years ago i couldn't get egg whites to work...
    do you have a link to the place on the rockland site where they recommend this?
    all i remember i had lots of yolks and a gooey sticky mess that
    didn't bind with the gelatin in the emulsion.
    they probably don't use the same recipe ( one for albumin prints i found in
    an old photographic annual that i used and gave up on ..

    john

  2. Photo Engineer

    Photo Engineer Subscriber

    Messages:
    28,362
    Joined:
    Apr 19, 2005
    Location:
    Rochester, NY
    Shooter:
    Multi Format
    Don, years of experience by myself and Mark Osterman indicate that a subbing layer for plates (and indeed most coatings) is not needed and that KRLF with hardener causes no problems with hand coated plates. Perhaps it is the food grade gelatin you are using. We used photograde gelatin.

    PE

  3. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    hi ron
    what is KRLF
    kodak regular fixer with hardener?

    and for what its worth, i have used food grade gelatin
    since the 1980s with rockland products no problems. i found a box of old
    plates a few days ago, they look exactly like they did
    when they were made ...

    thanks !
    john

    Last edited: Sep 18, 2017
  4. Photo Engineer

    Photo Engineer Subscriber

    Messages:
    28,362
    Joined:
    Apr 19, 2005
    Location:
    Rochester, NY
    Shooter:
    Multi Format
    Kodak Rapid Liquid Fixer, (KRLF) is the liquid Ammonium Hypo version of F5, the formula for which is well known.

    There are problems with the large variation in food grade gelatins, including Bloom Index and hardening capability as well as additives.

    PE

  5. Nodda Duma

    Nodda Duma Subscriber

    Messages:
    1,764
    Joined:
    Jan 22, 2013
    Location:
    Brookline, NH
    Shooter:
    Multi Format
    KRLF with Hardener works great for dry plates as well!

  6. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    thanks for the info on the fixer ! i didn't remember the abbreviation :smile: but
    knew the fixer !
    i have been using either the old professional sodium thiosulfate ( with hardener )
    since i somehow had a bag purchased and never used, or sprint speed fixer with hardener added ...

    i guess i've been lucky with knox, never a problem ( have used it with cyanotypes as well )

    knocking wood

  7. Photo Engineer

    Photo Engineer Subscriber

    Messages:
    28,362
    Joined:
    Apr 19, 2005
    Location:
    Rochester, NY
    Shooter:
    Multi Format
    Not everyone has good luck making images with Knox gelatin. I would say that that is one of the areas of the most complaints/questions both Mark Osterman and I get.

    PE

  8. hoffy

    hoffy Subscriber

    Messages:
    2,884
    Joined:
    Jan 21, 2009
    Location:
    Adelaide, Au
    Shooter:
    Multi Format
    Its good to see this thread pop up. It reminds me that I have a 3 year old Rockaloid kit sitting in my cupboard at home!

    Could anyone tell me if the secret sauce part of the developer would be OK?

  9. DonF

    DonF Member
    Ads Enabled

    Messages:
    239
    Joined:
    Jul 19, 2016
    Location:
    Saint Charles, Il
    Shooter:
    Large Format
    I'm very sorry, I was mistaken on this. In the instruction sheet for AG+ on the Rockland site, they describe gelatin subbing for vitreous surfaces using Knox food-grade gelatin. Against their advice, I tried it on aluminum trophy plates to very poor results. Nowhere do they suggest egg whites for gelatin emulsion.

    "Gelatin pre-coat (subbing) for glass and glazed ceramics: You will need some powdered laundry detergent and some unflavored gelatin such as the Knox brand. These items are sold at larger grocery stores. Scrub the glass or ceramic with hot water and powdered detergent until the rinse water does not bead up but leaves a uniform film when drained off. At this stage, the glass is chemically-clean. Sprinkle 1 level teaspoon (5 grams) of gelatin onto the surface of one cup (250 cc) of cold water. Allow it to swell for 5 minutes or more, then heat to melt the gelatin. Pour some of the hot solution over the chemically-cleaned glass. Drain completely and dry thoroughly before coating with emulsion."

    Best,

    Don

  10. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    thanks don :smile:

    hi hoffy ...

    is it the pre mixed stuff that is liquid or the powder-kit?
    if it is the liquid it the part a is dektol and probably dark and no good,
    the powder .. i am guessing as long as nothing is clumped it is OK ..
    look at donF's recipe in this thread if your dektol is toast use enough
    dektol for 8oz. in the rockland kit ... my memory might be off, but
    i think a gallon of developer is made with a quart of stock ( 1:4 )
    have fun!
    john

  11. hoffy

    hoffy Subscriber

    Messages:
    2,884
    Joined:
    Jan 21, 2009
    Location:
    Adelaide, Au
    Shooter:
    Multi Format
    I haven't dug it out yet, but yes, I'm talking the liquid.

  12. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    i think it is supposed to be almost clear / "straw" colored ( the part a / dektol )
    im not sure what the other stuff is supposed to look like, i imagine cause it is fixer and thiocyanate and sodium carbonate, it is clear?

    good luck !
    john

    ps if you do glass plates instead of black metal, they are greenish ( normal ) ..
    metal isn't green ..

  13. DonF

    DonF Member
    Ads Enabled

    Messages:
    239
    Joined:
    Jul 19, 2016
    Location:
    Saint Charles, Il
    Shooter:
    Large Format
    The Ammonium Thiocyanate stock solution is completely clear. The dry stuff clumps like crazy and must be broken up with an awl or ice pick. Dissolving it in water is highly endothermic. Frost almost forms on the beaker! The Dektol is clear when mixed. No Sodium Carbonate is in the Rockland recipe. There is Sodium Sulfate (NOT Sulfite!!), which is also clear when mixed.

    The final addition of Thiocyanate results in a strong Ammonium smell. The solution should be room temperature when the addition is done.

    The mixed developer turns the color of strong black tea after a few weeks. Air in the bottle accelerates the process. I just discard it when it looks like that. I store in an amber jar in the dark.

    Rockland says to "ripen" the developer overnight, but I have used it after only a few hours from mixing with no issues.

    The developer tray develops a sludge after a few plates, depending upon the density of the image. I replace the developer frequently. The sludge tends to stick to the tray surfaces. If not cleaned between plates, it can cause metallic stains on the plate.

    Don

  14. Sponsored Ad
  15. markfitzgerald

    markfitzgerald Member

    Messages:
    20
    Joined:
    May 28, 2015
    Shooter:
    Large Format

    I must be doing something wrong. I followed your recipe, but all I get when I try to develop it is a tan-colored piece of glass. I ordered the chems from ArtCraft, and mixed it up to your specs. I also tried it with a dry plate made by jason lane, and got the same thing. A very faint visible image but other than that, just a blank. If I develop the same plate in a 1:31 L-110, I get a nice negative, but I can't seem to get the positive developer to do anything. It does smell like ammonia though!

  16. DonF

    DonF Member
    Ads Enabled

    Messages:
    239
    Joined:
    Jul 19, 2016
    Location:
    Saint Charles, Il
    Shooter:
    Large Format
    After final mixing in of the thiocyanate solution, it should sit 12 hours or so to "season" (per Rockland). I have only used it for tintypes on blackened metal plates, never on glass. If your're attempting ambrotypes on glass with gelatin AGPlus emulsion, I would think it would work, but have not tried this. I mixed up a batch a few weeks back and it worked fine, though. It seems to keep a few weeks in a filled and tightly stoppered bottle in the dark.

    Best,

    Don

  17. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    hi markfitzgerald

    if you put your glass plate infront of something BLACK you might see your postive image.
    what happens with the silver gelatin tintype on metal or glass or paper ( black ) is the following
    the image develops and fogs, and the thiocyaniate bleach lightens the blacks to be lighter as
    the whites ( clear ) show the black of the plate. so ... if you are doing your exposures on clear glass
    or something that isn't black you won't really get the same effect.

    i've been meaning to do don's recipe too, but life has gotten in the way ..

  18. DonF

    DonF Member
    Ads Enabled

    Messages:
    239
    Joined:
    Jul 19, 2016
    Location:
    Saint Charles, Il
    Shooter:
    Large Format
    I agree! The plate should appear as a normal negative against a light background (with less density) and a positive when front lit with a black background. I read that the thiocyanate alters the development process such that very fine reflective particles of silver are formed rather than the dark-appearing tangled threads of silver as in a negative. Dunno’,but it does work...
    and looks wonderful when the stars align and work in your favor.

    Best,

    Don

  19. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    i forgot to mention ... ..

    at least with the rockland developer ( as i said i haven't used don's )
    reversals on GLASS have a funky green hue to them, if you
    have ever developed azo paper in dektol or ansco 130, it is
    the same sort of greenish hue ... the metal ones don't look greenish :smile:

    ( a link to greenish hue glass reversals
    http://www.nanianphoto.com/blog/4-glass-plates-then-4-paper-prints/4plate1-186-sm/
    if you click on the image you can see it better ... )

    Last edited: Feb 24, 2018
  20. markfitzgerald

    markfitzgerald Member

    Messages:
    20
    Joined:
    May 28, 2015
    Shooter:
    Large Format
    I did let it sit over night before use. I've used the "real" rockland kit before and had some limited success, but this isn't a reversal issue where it needs to be on a black background. it just never clears. It looks like a spudgy mess. Here's a sample of a Jason Lane Dry Plate (pre coated gelatin). After nothing came up after about 10 minutes, I poured some working strength l-110 over it and left it for a couple of minutes while I cleaned up the rest of the trays IMG_6821.JPG . So there is/was definitely something exposed on the plate. I was doubting myself for a bit thinking maybe I didn't expose it. Maybe I'll start over with another batch. I do still have some of the Ammonium Thiocyanate stock solution so I should have three more attempts at it.

    Last edited: Feb 26, 2018
  21. markfitzgerald

    markfitzgerald Member

    Messages:
    20
    Joined:
    May 28, 2015
    Shooter:
    Large Format
    I wonder if the issue is that I’m trying to use liquid light? I am getting nothing. The stuff just stays tan in the developer. I did overheat the bottle a bit when I was transferring to smalller containers. I’m sure that didn’t help...

  22. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    are you using regular liquid light or vc or the ag+ or are you still using jason's plates ?
    if you are using liquid light doulbe coat your glass, that is the advice i was given by the
    guy who founded the company, the ag+ has more silver in it so it gives a stronger image
    he suggested double coating would be better for non ag+ emulsions.
    if you suspect your emulsion is bad, coat a scrap of paper and put a penny on it and turn the lights on
    and put it in regular developer ( dektol type developer )and see if the image is white and black
    liquid emulsion is pretty slow ... i've used some that was like 15 years old and gotten it to produce images it needed
    more light and stronger developer ( and fixer wtih hardener ! )
    you can make a test strip with a regular piece of paper to ID your exposure time too ... just like under an enlarger..
    maybe you are under exposing / over exposing your image ..

  23. elocinexx

    elocinexx Member

    Messages:
    5
    Joined:
    Mar 24, 2018
    Location:
    US
    Shooter:
    Multi Format
    I'm looking to start this process, but I was leaning towards liquid light and tin plates (from another company) instead of getting the kits. From what I have read, liquid light can be developed/fixed in normal everyday chemistry. But has anyone tried it with Don's recipe for developer? I am curious if it would yield better results to use the Dektol combo rather than just D76. Anyone have experience with this? My biggest fear is having a bad chemical rxn if the liquid light is not compatible with Dektol and Ammonium Thiocyanate. Any advice would be appreciated. I have yet to order the liquid light or Ag+ so I am open to both.

  24. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    i haven't used don's recipe yet. .. its on my to-do list ...
    read the info on using other metal plates, you might have to treat them
    before you use them because from what i remember rockland does something
    to them so the emulsion adheres ( sorry i can't remember what it is they do ).
    liquid light / ag+ or whatever emulsion you will be using is paper emulsion so dektol
    or any print developer will probably work better than d76. without don's chemistry (or docklands)
    normal every day chemistry will give you a negative if exposed in-camera, the special developer
    fogs, and bleaches the image... if you are enlarging or making contact prints onto the metal regular chemistry
    is the way to go, and you will have an image ( postiive ) image on the plate.
    have fuN!

  25. elocinexx

    elocinexx Member

    Messages:
    5
    Joined:
    Mar 24, 2018
    Location:
    US
    Shooter:
    Multi Format
    Thanks for the info jnanian! The plates I ordered are "'Modern Collodion' Tintype Plates" that BH carries. They are advertised as being idea for wet plate and tintypes / alt. processes. I am hoping that they will be okay. You 15 for the same price as 10 (with the shipping) of the Rockaloid kind. I was leaning towards liquid light because from what I have read so far, it can be applied to a larger variety of surfaces. Maybe I am wrong and Ag+ can be applied the same way too? Also, is there anything special for disposal of the Dektol/Ammonium Thiocyanate developer?

  26. jnanian

    jnanian Advertiser Advertiser
    Ads Enabled

    Messages:
    25,463
    Joined:
    Jun 21, 2003
    Location:
    paswonquitte
    Shooter:
    Multi Format
    hi again

    https://www.photrio.com/forum/threads/rockland-colloid-should-i-bother.112558/page-3#post-1817235
    donF speaks about havng adhesion issues with trophy aluminum plates. i am guessing that maybe what you
    have might be similar but a different "brand" ? he solved his problem by cleaning the plates well and then putting a layer of gelatin on the plate as a sub layer/
    photoengineer warns about food grade gelatin, you might contact photographers formulary or artcraft chemical or bostick and sullivan
    and purchase some 250 / photo grade gelatin. its pretty inexpensive .

    i have my developer (used) in a haul-drum. not sure what your recovery situation might be. its best to do a little research for your area about
    what you use and how it can be disposed. i'm also trying to figure out a non-thiocyanate developer. cause id rather not use harsh chemistry

    good luck !
