I’ve run a bracketed set of exposures, from +3 to -2, based on the “box speed” of 320. I used the CatLabs recommended time for Rodinal 1+25. Incident metering.
The film is drying, but my initial impression is that within these parameters, my EI is around 400.
I‘ll post some pics of the negs later.
My sensitometer is very simple. It is not calibrated. It is entirely DIY. I used a piece of aluminum that is 6 x 1.5 x 0.5" and attached a piece of 1/8 inch thick glass with a soft, fabric hinge. I am using an uncalibrated Stouffer step tablet, as you can see in the picture attached here. I use an on-easel light meter to estimate the amount of illumination, and I am using a shutter installed in place of the enlarger lens (for 0.25 sec. to avoid potential reciprocity complications). I expose a piece of film about six inches long, one at a time, through the step tablet. It is essentially a contact print. Then I transfer the exposed strips of film to a lightproof box. I then process the film normally, dry it, and then read the densities with a densitometer. I then enter the numbers into a program I wrote to run the analysis. It's not a perfect system by any means, but I think it can get one at least a ballpark estimate of a film's performance.Could you please provide a bit more details how your sensitometer works? Do you have a calibrated step-wedge that you put in front of the film as is done in commercial sensitometers? Or do you have a slide that covers parts of your film as your make multiple exposures (similar to how you would do exposure tests strips for printing)?
Please continue your experiments. I have little interest in Catlabs' films but your tests and methodology are fascinating!
35mm and metering in camera?
Here's the set. Three stops either side of the "0", or 320 ISO on my Sekonic meter. Somewhere between 320 and 640 for these would be pretty nice. 200/160 is a little crispy.
View attachment 319027
Here's the set. Three stops either side of the "0", or 320 ISO on my Sekonic meter. Somewhere between 320 and 640 for these would be pretty nice. 200/160 is a little crispy.
View attachment 319027
I did a bit more work on the comparison between Arista Edu Ultra 100 and Catlabs Pro 320 last night and, it turns out, I had been a bit off with my preliminary findings. I ended up having to adjust each curve to give it the average gradient of 0.62, per the ISO speed point procedure (described in a lot of sources, incl. Davis, 1993). This type of adjustment provides a simulation of how these curves would look if they were processed to precisely the same G. It's necessary to do that, I think, as it's very difficult to get the same G for two different films, even with the strictest of exposure and processing controls. In the image attached here, the dotted lines represent these "ideal" ISO curves. Speed points measured from these curves are marked with the vertical dotted lines (blue - Arista, red - Catlabs). The difference is film speed measured this way is about 0.549415 stops if favor of the Arista film, so less than I originally estimated in my preliminary analysis. I am sorry about that. I should be more careful next time. So, after these corrections, the film speed I am getting are ISO 85.15897 for Arista, and ISO 58.26475 for the Catlabs film.
Those of you who looked at my previous analysis of film curves, noticed that the ISO values obtained there were a bit lower. The film simply received significantly less exposure than it needed to produce well-formed curves. It has been found in the literature that curves with long toes are particularly difficult to analyze and are susceptible to film speed estimate errors by the ISO 0.1 criterion. (e.g., Nelson and Simonds, 1955). That amount of exposure, by the way, was perfectly suitable for other medium-speed films,
such as Kodak 400TX and Fujifilm Neopan 400.View attachment 319007
Again, in my opinion, the actual ISO value does not matter much, as most photographers come up with their own personal EI value, anyway. We all have different cameras, different exposure meters, different techniques, different processing, digitization, printing, etc. To be clear, I am absolutely not disputing the fact that some photographers are getting excellent (for them) results exposing at EI 200. What I think is more important is that, under controlled conditions, the Catlabs film does, indeed, appear slower than other popular films, such as Kodak 400TX and Arista Edu Ultra 100 (most people agree it's Foma 100).
It would be great if other photographers were able to produce data of their own, regardless of how they were obtained. I really liked the idea of using the methods described @pentaxuser and @BradS earlier in the thread. I think the "Fred Picker" method would be interesting, as well. There's a great method described in Way Beyond Monochrome (Lambrecht and Woodhouse , 2011).
Yes, that is correct.Good work! Thanks!
This is an interesting result. Just to make sure I understand, We're looking at, left to right, -3, -2, -1, 0, +1, +2, +3 stops of exposure compensation...or in other words, ASA 2560, 1280, 640, 320, 160, 80, 40...yes?
Seems like the the DX encoded speed, ASA1250 would produce printable negative, if a little thin.
and ASA 80 looks a little dense for my taste.
Rightmost two start to get some definition in deep shadows, but are massively overdeveloped at that point.
This film looks worse and worse with every post.
Rightmost two start to get some definition in deep shadows, but are massively overdeveloped at that point.
This film looks worse and worse with every post.
...ISO 85.15897...ISO 58.26475...
Thank you for this information. Great idea to use a shutter! Your system is as good as any commercial sensitometer and probably as accurate. Your main uncertainty would come from the exposure measurements (light meter and shutter combined). With good light meter and shutter you should be within 1/3 of a stop, more than adequate for your tests.My sensitometer is very simple. It is not calibrated. It is entirely DIY.
Thank you for all of your excellent work and these detailed explanations of equipment, process and procedure.
I'm having a little trouble interpreting the curves here. In particular, they seem...straighter, less curvy than expected. Is that because were only seeing ~10 stops of exposure along the horizontal axis - where we usually see ~14 (see for example, Ilford data sheets)? Or is it because the exposure given is...as you say, enough for ASA400 film...effectively getting up off the toe?...or, some combination of both of these? Also, is the vertical scale (effectively) logarithmic? That is, you've taken the base 10 log of the quantity and plotted that on a linear scale...yes? Is that also what Ilford does? (They're reticent about their equipment, process and procedure).
Thanks again for all of your work and contributions here.
How can anyone take these results seriously? They have pathetically few significant digits. At least a dozen are necessary.
Here's the set. Three stops either side of the "0", or 320 ISO on my Sekonic meter. Somewhere between 320 and 640 for these would be pretty nice. 200/160 is a little crispy.
View attachment 319027
These are all shot at 200, processed in Rodinal 1+25 at the CatLabs recommended time (which I think is a touch too much). But, it is workable, and the film is sharp and has nice grain. It has its own look, for sure.
View attachment 319039
View attachment 319040
Those look really good. You got my curiosity up for sure.
I can change it in my software from one to the other. I've seen it done either way in the literature.
I find Ilford "Relative log exposure" more intuitive as more exposure results in higher negative density. Kodak, Foma and many other film manufacturers use this convention.The Ilford "Relative log exposure" shows a progression from 0 to 4, whereas I chose the reversed axis convention.
