Digital camera ISO speed and exposure index
In
digital camera systems, an arbitrary relationship between exposure and sensor data values can be achieved by setting the
signal gain of the sensor. The relationship between the sensor data values and the lightness of the finished image is also arbitrary, depending on the parameters chosen for the interpretation of the sensor data into an image
color space such as
sRGB.
For digital photo cameras ("digital still cameras"), an
exposure index (EI) rating—commonly called
ISO setting—is specified by the manufacturer such that the sRGB image files produced by the camera
will have a lightness similar to what would be obtained with film of the same EI rating at the same exposure. The usual design is that the camera's parameters for interpreting the sensor data values into sRGB values are fixed, and a number of different EI choices are accommodated by varying the sensor's signal gain in the analog realm, prior to conversion to digital. Some camera designs provide at least some EI choices by adjusting the sensor's signal gain in the digital realm ("expanded ISO"). A few camera designs also provide EI adjustment through a choice of lightness parameters for the interpretation of sensor data values into sRGB; this variation allows different tradeoffs between the range of highlights that can be captured and the amount of noise introduced into the shadow areas of the photo.
Digital cameras have far surpassed film in terms of sensitivity to light, with
ISO equivalent speeds of up to 4,560,000, a number that is unfathomable in the realm of conventional film photography. Faster processors, as well as advances in software noise reduction techniques allow this type of processing to be executed the moment the photo is captured, allowing photographers to store images that have a higher level of refinement and would have been prohibitively time-consuming to process with earlier generations of digital camera hardware.
The ISO (International Organization of Standards) 12232:2019 standard
The ISO standard ISO 12232:2006[66] gave digital still camera manufacturers a choice of five different techniques for determining the exposure index rating at each sensitivity setting provided by a particular camera model. Three of the techniques in ISO 12232:2006 were carried over from the 1998 version of the standard, while two new techniques allowing for measurement of JPEG output files were introduced from CIPA DC-004.[67] Depending on the technique selected, the exposure index rating could depend on the sensor sensitivity, the sensor noise, and the appearance of the resulting image. The standard specified the measurement of light sensitivity of the entire digital camera system and not of individual components such as digital sensors, although Kodak has reported[68] using a variation to characterize the sensitivity of two of their sensors in 2001.
The Recommended Exposure Index (REI) technique, new in the 2006 version of the standard, allows the manufacturer to specify a camera model's EI choices arbitrarily. The choices are based solely on the manufacturer's opinion of what EI values produce well-exposed sRGB images at the various sensor sensitivity settings. This is the only technique available under the standard for output formats that are not in the sRGB color space. This is also the only technique available under the standard when multi-zone metering (also called pattern metering) is used.
The Standard Output Sensitivity (SOS) technique, also new in the 2006 version of the standard, effectively specifies that the average level in the sRGB image must be 18% gray plus or minus 1/3 stop when the exposure is controlled by an automatic exposure control system calibrated per ISO 2721 and set to the EI with no exposure compensation. Because the output level is measured in the sRGB output from the camera, it is only applicable to sRGB images—typically JPEG—and not to output files in raw image format. It is not applicable when multi-zone metering is used.
The CIPA DC-004 standard requires that Japanese manufacturers of digital still cameras use either the REI or SOS techniques, and DC-008[69] updates the Exif specification to differentiate between these values. Consequently, the three EI techniques carried over from ISO 12232:1998 are not widely used in recent camera models (approximately 2007 and later). As those earlier techniques did not allow for measurement from images produced with lossy compression, they cannot be used at all on cameras that produce images only in JPEG format.
The
saturation-based (SAT or Ssat) technique is closely related to the SOS technique, with the sRGB output level being measured at 100% white rather than 18% gray. The SOS value is effectively 0.704 times the saturation-based value.
[70] Because the output level is measured in the
sRGB output from the camera, it is only applicable to sRGB images—typically
TIFF—and not to output files in raw image format.[
citation needed] It is not applicable when multi-zone metering is used.
The two
noise-based techniques have rarely been used for consumer digital still cameras.[
citation needed] These techniques specify the highest EI that can be used while still providing either an "excellent" picture or a "usable" picture depending on the technique chosen.[
citation needed]
An update to this standard has been published as ISO 12232:2019, defining a wider range of ISO speeds.
