I've followed a different path for multi-layer gum prints in the last 3 month. A lot of trial and error, as well...
I made CMYK separations and applied different adjustment curves for each color. The K layer was the last - a Palladium layer over the gum color layers.
Still a lot to work on this method but, IMO, promising...
My best color balanced result till now (but, well, the layers alignment is a bit off..) is this:



Gelatin sized Fabriano Artistico 600g/m2.


Dan Pavel

Member
Joined
Sep 11, 2017
Messages
188
Location
Constanta, Romania
Format
Multi Format
This is an earlier, better aligned test with 2 gum layers/color, 1 layer of Palladium, different exposure times and the same adjustment curves as in the first test.
The color balance and saturation is different with 2 layers/color, of course.

OP
OP
Bob Carnie

Bob Carnie

Subscriber
Joined
Apr 18, 2004
Messages
7,734
Location
toronto
Format
Med. Format RF
Interesting I would like to try palladium over the gum layers - Curious did you have to do some kind of sizing layer over the gum... if not how did the palladium get into the gum layers ??


Dan Pavel

Member
Joined
Sep 11, 2017
Messages
188
Location
Constanta, Romania
Format
Multi Format
Yes, after the gum layers dried I applied a gelatin layer, otherwise the Palladium washes away. Palladium over gelatin needs a longer exposure (~ 2 times longer than usually).

OP
OP
Bob Carnie

Bob Carnie

Subscriber
Joined
Apr 18, 2004
Messages
7,734
Location
toronto
Format
Med. Format RF
So the palladium soaks into the Gelatine?? this sounds like a great finish of the final print.


DennyS

Member
Joined
Oct 5, 2010
Messages
77
Format
Hybrid
I've recently been doing some work in gum over cyanotype, two layers of gum over a Ware cyanotype layer. An advantage for me is that the cyanotype layer adds enough punch to eliminate the need for a platinum/palladium or K layer. It's not the same look, but I think it can work for some images. Here's an example on Platine...

OP
OP
Bob Carnie

Bob Carnie

Subscriber
Joined
Apr 18, 2004
Messages
7,734
Location
toronto
Format
Med. Format RF
I've recently been doing some work in gum over cyanotype, two layers of gum over a Ware cyanotype layer. An advantage for me is that the cyanotype layer adds enough punch to eliminate the need for a platinum/palladium or K layer. It's not the same look, but I think it can work for some images. Here's an example on Platine...
Really nice Denny A lot of people I know do gum over Cyanotype...


DennyS

Member
Joined
Oct 5, 2010
Messages
77
Format
Hybrid
Thanks Bob. I've taken an unusual (for me) approach, treating the sky as if it were a pure cyanotype (working from a B&W copy of the image) with a simple cyanotype curve, and blocking any contribution from the gum layers. The result can be "storybook" cyan skies.


Andrew O'Neill

Moderator
Joined
Jan 16, 2004
Messages
10,142
Location
Coquitlam,BC Canada
Format
Multi Format
I have been tweaking the process since last summer. Normally I lay down yellow first, magenta, then cyan. Recently I'v'e been farting around with laying down a K layer (for shadows only) first, followed by yellow, etc. That threw the colour balance out for some strange reason. After more tweaking, I got decent results. Yesterday, I decided to lay down the cyan layer after the K layer... the yellow, then magenta. I got the nicest print ever. I'll have to post it here when I get home.


jim10219

Member
Joined
Jun 15, 2017
Messages
1,635
Location
Oklahoma
Format
4x5 Format
I find if you just do three layers, it's best to start with your lightest (yellow) and work your way to your darkest color (cyan). That way your darks are sufficiently dark. With four colors (CMYK), I actually run them in that order, like you would on a printing press. The lighter colors mix better with the darker colors if they're applied over them. The problem of the washed out blacks is remedied by the final black layer. But keep in mind this layer needs to be printed a lot softer than the other layers (about 20% strength).


Andrew O'Neill

Moderator
Joined
Jan 16, 2004
Messages
10,142
Location
Coquitlam,BC Canada
Format
Multi Format
My darks were sufficiently dark going the yellow-magenta-cyan order. The K gives it more clout. In all the colour printing that I've done, be it lithography, intaglio, serigraphy, the K always went down last... I would never have put it down first. For this particular image that I've been working with, it looks best laid down first, followed by cyan, yellow, magenta. This K layer is quite transparent, too. Much more than C layer. I'll try it this way with another image and see what happens.


Fraunhofer

Member
Joined
Jan 1, 2016
Messages
208
Location
East coast
Format
Multi Format
I am reporting my first baby steps in tricolor gum or any gum for that matter. 2 weeks ago I just went to the local art supply store bought some gum and water colors and after doing a few test strips and one totally failed attempt, I got this


Which is too dark and too much magenta... Note these mushrooms do have really striking colors and are all edible and were quite delicious. The picture was taken with an Iphone SE.

The upshot: I encourage folks to try this, it is an economical process and first results are fairly easy to obtain. Now, getting great results may be a whole different game...

Next I will try this print with 1 stop less magenta and 1/2 stop less cyan exposure.


Fraunhofer

Member
Joined
Jan 1, 2016
Messages
208
Location
East coast
Format
Multi Format
Very nice, fraunhofer. Which pigments are you using? I've noticed huge improvements in my gum prints by switching to better pigments... Daniel Smith.

Thanks. I use student grade Newton & Winsor Cotman, but I got a package today with Daniel Smith colors and some Fabriano paper...


Andrew O'Neill

Moderator
Joined
Jan 16, 2004
Messages
10,142
Location
Coquitlam,BC Canada
Format
Multi Format
Cotman is what I was using at first... I was using their water colours for carbon printing. Crappy for gum prints, though. The Daniel Smith water colours are far superior. Fabriano paper is excellent. I'm hooked on Hahnemuhle platinum rag.


Fraunhofer

Member
Joined
Jan 1, 2016
Messages
208
Location
East coast
Format
Multi Format
Question: how do you size your paper? Currently I am using Strathmore Printmaking 400 and that works fine without sizing, I just preshrink it in hot water.

OP
OP
Bob Carnie

Bob Carnie

Subscriber
Joined
Apr 18, 2004
Messages
7,734
Location
toronto
Format
Med. Format RF
Hahnemuhle Platinum Rag is my paper of choice as well, also Daniel Smith pigments... I pre shrink the paper but really only in room temp water, I like to let the paper sit for at least a half hour and really soak.
I have never sized paper , used tween , PVA that others use

50% humidity in the room seems to be the best for my work.
Doing 4 layer registration with 20 x 24 images this week with no issues.


Andrew O'Neill

Moderator
Joined
Jan 16, 2004
Messages
10,142
Location
Coquitlam,BC Canada
Format
Multi Format
I sized at first, but that was with a crappy paper that needed it. HPR paper doesn't need it. I shrink the paper with luke warm water. Some people use boiling hot water (I was at first), but it's not necessary... I feel that that is too hard on the paper fibres.


Fraunhofer

Member
Joined
Jan 1, 2016
Messages
208
Location
East coast
Format
Multi Format
Andrew, Bob,

Thanks, that is good news. Sizing and dealing with hardeners etc. seems like a real PITA, so glad to hear I can get away without.

OP
OP
Bob Carnie

Bob Carnie

Subscriber
Joined
Apr 18, 2004
Messages
7,734
Location
toronto
Format
Med. Format RF
Here is a link to a video I just had done to show how to separate film for tri colour printing.


Andrew O'Neill

Moderator
Joined
Jan 16, 2004
Messages
10,142
Location
Coquitlam,BC Canada
Format
Multi Format
Here is a link to a video I just had done to show how to separate film for tri colour printing.


Looks great, Bob! I'll watch it at lunch as I've got a bunch of grade niners staring at me at the moment!


Andrew O'Neill

Moderator
Joined
Jan 16, 2004
Messages
10,142
Location
Coquitlam,BC Canada
Format
Multi Format
Here is a link to a video I just had done to show how to separate film for tri colour printing.


Bob, some excellent pointers in there. Thank you so much for sharing!
