A Balda Super Baldax.
Cleaned up the shutter and sparingly lubricated anything which looked like it needed it. The shutter was taking about five seconds to close regardless of setting due to oil on the blades. It now seems to run perfectly.
This is the first time I have attempted a clean out and re-lubrication of a shutter. My previous attempts at cleaning only have had limited success. It took me a long time to work out how to put back the ring which adjusts the shutter speeds and once it was all back together I was surprised at how easily and smoothly this ring turns. So much so that at first I thought I had not done it correctly and it wasn't engaging on anything. However, all speeds appear to be correct.
The arrangement to lock the folding mechanism in place so it can't be folded up when focused anywhere but infinity needed some re-alignment and the viewfinder and rangefinder needed fifty years worth of dust cleaning from them.
I also had a look at the overly complex auto spacing wind on mechanism. I was trying to see if I could simplify it and just use the red window to align the frame numbers but I ended up putting it back together as intended. These mechanisms are first turned the wrong way until they stop then turned the right way, also until they stop. The wrong way turn engages a drive pin at a different place for each frame to compensate for the gradual buildup of film on the spool and the correct rotation advances the film an amount pre-determined by the pin position. However it tends to stop too early so frames overlap. I have read that it is because the spool diameter is smaller now than it was fifty years ago and some people put tape on the spool to increas its size. I think I will just open the window and wind it on a bit to the next number.
It is now ready to test.
This camera came from an old chap who lived at the retirement home my wife used to work at. She brought it home for me to look at as it was not working. I lent him a 6x6 Zeiss folder to use whilst I had his camera but it turns out that he has now moved several hundred miles away to be closer to his family so we have ended up in possession of each others cameras. If the family ever get in touch, I will gladly give it back but until then, I will get some use out of it on his behalf.
Steve.
