Shift lens technique for low light and low ISO

Discussion in '35mm Cameras and Accessories' started by quixotic, Aug 12, 2018.

  1. quixotic

    quixotic Member
    Ads Enabled

    Messages:
    122
    Joined:
    Jan 28, 2008
    Location:
    Red Deer, Alberta, Canada
    Shooter:
    Medium Format
    Just wondering what others have done under similar situations.

    Given that one is supposed to meter and then shift, how can one do this when using low ISO film (25 in my case) and low light conditions (eg, a cathedral interior), and a camera which only has marked shutter speeds down to one second?

    I guess I could use an external light meter, and then the bulb setting on the camera. Another option might be to use auto exposure, and then turn the exposure compensation dial a notch or two to give a bit of extra light.

    Any thoughts? (thanks in advance).

  2. AgX

    AgX Member

    Messages:
    17,570
    Joined:
    Apr 5, 2007
    Location:
    Germany
    Shooter:
    Multi Format
    But why is one "supposed to meter and then shift" ?

  3. Shift then meter.

  4. locutus

    locutus Member

    Messages:
    447
    Joined:
    Jun 9, 2009
    Location:
    Finland
    Shooter:
    Multi Format
    Essentially, lightmeters too have an acceptance angle in which they see the cone of light coming from the lens.

    Shifting radically moves it away, and as a precaution SLR manufacturers state you shouldn't trust meter measurements.

    I haven't done the geometry magic on how much effect it has, but i do expect you might be off by as much as a stop at 12mm of shift.

    Personally, inside of a cathedral in low light while shooting shift? I would use a external meter and incident meter for your foreground.

  5. Poisson Du Jour

    Poisson Du Jour Member
    Ads Enabled

    Messages:
    5,387
    Joined:
    Jul 1, 2008
    Location:
    Geelong & Richmond AUS
    Shooter:
    Multi Format
    Groups:
    Meter the scene, lock the reading in (e.g. with AEL), then apply shift and/or tilt. This is the standard technical procedure when using Canon's TS-E lenses or Nikon's equivalent tilt/shift lenses. There is no mention of what lens you are using.
    This is because the light is distorted coming through the lens when tilt and/or shift is applied, and will not strike the meter as it would with a non shift/tilt lens. Similarly, autofocus is also useless, hence manual focus and adjustment of the focus 'peg' using tilt (in such lenses with dual function).
    A separate hand held meter effectively gets around all of this if the camera is set to Bulb or other means are used to hold the shutter open for a longer exposure than the camera meters.
    You will still need to account for reciprocity correction beyond 1 second if the film requires it.

    Last edited: Aug 12, 2018
  6. OP
    OP
    quixotic

    quixotic Member
    Ads Enabled

    Messages:
    122
    Joined:
    Jan 28, 2008
    Location:
    Red Deer, Alberta, Canada
    Shooter:
    Medium Format
    Thanks. That sounds like a good rule of thumb. But on auto-exposure, I should twist the exposure compensation dial to give it a stop of extra light, right? (just wanna make sure I'm going the right way).

    I'd use a light meter, but on vacation, I need something a bit faster (my wife already does enough exasperated sighing and looking at her watch when I stop for just one more photo).

  7. OP
    OP
    quixotic

    quixotic Member
    Ads Enabled

    Messages:
    122
    Joined:
    Jan 28, 2008
    Location:
    Red Deer, Alberta, Canada
    Shooter:
    Medium Format
    Currently a 24mm Zuiko shift, but I'd expect that they'd all behave in a somewhat similar manner.

  8. Poisson Du Jour

    Poisson Du Jour Member
    Ads Enabled

    Messages:
    5,387
    Joined:
    Jul 1, 2008
    Location:
    Geelong & Richmond AUS
    Shooter:
    Multi Format
    Groups:
    Yes they do. Any time you apply shift, the meter's reading, unless locked in, is considered in error.

  9. ciniframe

    ciniframe Member
    Ads Enabled

    Messages:
    453
    Joined:
    Jul 3, 2014
    Shooter:
    Sub 35mm
    Bracket the exposure. Or has film grown so expensive folks no longer bracket?
    Anyhow, that's what I'd do.

  10. OP
    OP
    quixotic

    quixotic Member
    Ads Enabled

    Messages:
    122
    Joined:
    Jan 28, 2008
    Location:
    Red Deer, Alberta, Canada
    Shooter:
    Medium Format
    I'm guessing that in constant dollars, film is still about the same price as it was decades ago...maybe even cheaper.

    But I have done a test with auto-exposure on, and shift off, versus auto-exposure, full shift (10 mm's), and an exposure compensation of +1. I'll post the results when I get through the roll and it comes back from the lab.

  11. MattKing

    MattKing Subscriber
    Ads Enabled

    Messages:
    23,314
    Joined:
    Apr 24, 2005
    Location:
    Delta, BC, Canada
    Shooter:
    Multi Format
    As you are using a Zuiko shift lens, there is a decent chance that you are using an OM body.
    And if that OM body is a 2n, 2s, 4 or 4T, (plus a couple others I think) than auto-exposure is accomplished by taking readings off the film during exposure.
    So if I was using one of those bodies, I would just let the camera compensate automatically for any exposure variance contributed by the shift.

  12. wiltw

    wiltw Subscriber
    Ads Enabled

    Messages:
    2,445
    Joined:
    Oct 4, 2008
    Location:
    SF Bay area
    Shooter:
    Multi Format
    Nevertheless, Olympus instructions for the 24mm f/3.5 PC lens is to METER then SHIFT.

    Yes, my avatar is an OM-4 with 24mm f/3.5 PC

  13. AgX

    AgX Member

    Messages:
    17,570
    Joined:
    Apr 5, 2007
    Location:
    Germany
    Shooter:
    Multi Format
    That angle of view of a light meter vs. the angle of view of a lens issue is a matter of a seperate meter, not of the meter inside the optical path of the camera.
    The latter meter measures a fixed area on the focal plane, nonewithstanding the shift. Any light fall-off at the rim of the shifted image will affect both meter and film.
    (One could argue on the angle under which light falls onto the metering sensor and how that may affect the sensor differently than the film, but that is a very specific issue dependant on the design of the camera, for instance whether the metering sensor is placed behind the groundglass or in front of it. As SLRs use retrofocus lenses the rear opening angle is moderate anyway.)

    Last edited: Aug 13, 2018
  14. Usually the instructions say to meter first, then shift. If one is concerned, bracketing above and below the exposure might be a good way to be sure one captures the photograph, especially if one is using negative film.

  15. MattKing

    MattKing Subscriber
    Ads Enabled

    Messages:
    23,314
    Joined:
    Apr 24, 2005
    Location:
    Delta, BC, Canada
    Shooter:
    Multi Format
    I just read those instructions (from the link on the Olympus Sales Information File) and I think that what you are referring to applies only to use with the camera (OM-2) set for manual exposure.
    I think that the instructions for the OM-2 set to AUTO do not include such a recommendation.
    But those instructions could be worded more clearly.
    http://omesif.moosemystic.net/om-sif/lensgroup/manuals/35mm_f28_shift.pdf

  16. OP
    OP
    quixotic

    quixotic Member
    Ads Enabled

    Messages:
    122
    Joined:
    Jan 28, 2008
    Location:
    Red Deer, Alberta, Canada
    Shooter:
    Medium Format
    Thanks Matt. That's good to know. I guess I'll find out tomorrow, when my film gets developed.
    (I have an OM-4ti).

  17. btaylor

    btaylor Subscriber
    Ads Enabled

    Messages:
    758
    Joined:
    Dec 28, 2010
    Location:
    Los Angeles
    Shooter:
    Large Format
    quixotic, the best way to tell is to do an actual test as you have done and pick the best exposure. But it does seem quite obvious to me that if the exposure is measured off the film at the time of exposure in auto mode that is likely going to hit the exposure target.

  18. AgX

    AgX Member

    Messages:
    17,570
    Joined:
    Apr 5, 2007
    Location:
    Germany
    Shooter:
    Multi Format
    I assume, based on my on others' comments above, the advise to meter before shifting is not a camera-specific remark. But rather is referring to the center of (metering) interest being not (yet) in the center of the image.
    Think of the old advise to meter before panning and thus moving the centered subject out of center.

  19. wiltw

    wiltw Subscriber
    Ads Enabled

    Messages:
    2,445
    Joined:
    Oct 4, 2008
    Location:
    SF Bay area
    Shooter:
    Multi Format
    Certainly if one is using and OM with OTF metering during exposure, what you said is true. Unfortunately, one is forced to use 'averaging' via the pattern which printed on the curtain, rather than taking advantage of any spot metering with the multispot capability of the OM-4. And if one is using an OM-1, OTF is not a capability, nor with the OM-nn bodies..

    Olympus does not put in any information in the OM-4 user manual, pertinent to a shift lens, and the instructions for the shift lens predate the OM-4. The advisory about not exceeding 1/1000 in the displayed speed during Auto does not apply to the 1/2000 capable OM-4, but nonetheless nothing is said in OM-4 documentation.

  20. MattKing

    MattKing Subscriber
    Ads Enabled

    Messages:
    23,314
    Joined:
    Apr 24, 2005
    Location:
    Delta, BC, Canada
    Shooter:
    Multi Format
    Actually, my OM-G/OM-20 does feature OTF automatic exposure meter reading.
    As I rarely use that body in the special situations where OTF metering provides a particular advantage, and as that feature doesn't work with flash on that body, I forget about that feature.
    Also, as the OM-G/OM-20's automatic exposure metering is limited to a maximum exposure time of 2 seconds, it probably isn't the ideal body to use in those special situations.

  21. OP
    OP
    quixotic

    quixotic Member
    Ads Enabled

    Messages:
    122
    Joined:
    Jan 28, 2008
    Location:
    Red Deer, Alberta, Canada
    Shooter:
    Medium Format
    Well, here is the results of my makeshift test. Not a huge change with the shift. I'm just surprised at how little the exposure compensation changed things. 24mm shift test.JPG

  22. pentaxpete

    pentaxpete Subscriber
    Ads Enabled

    Messages:
    418
    Joined:
    Sep 23, 2010
    Location:
    Brentwood, England
    Shooter:
    Multi Format
    Groups:
    I have the loan of an OM-4Ti set which includes the Zuiko 35mm f2.8 'Shift' lens and i used 'Auto Exposure' with 'Spot' metering and photos came out perfectly -- here is one against the light with 'Spot'metering and Orange filter --
    Test 06.jpg

  23. OP
    OP
    quixotic

    quixotic Member
    Ads Enabled

    Messages:
    122
    Joined:
    Jan 28, 2008
    Location:
    Red Deer, Alberta, Canada
    Shooter:
    Medium Format
    Yeah, I've come to the conclusion that even if there was a difference in light admittance with shift, it's not enough to worry about. Even when I used slide film on a Sylvestri (no internal meter), I don't ever remember altering shutter speed or aperture, and the results seemed fine.
