Sensor noise in film scanner

Discussion in 'Scanning and Scanners' started by alanrockwood, Aug 30, 2018.

  1. pentaxpete

    pentaxpete Subscriber
    Ads Enabled

    Messages:
    422
    Joined:
    Sep 23, 2010
    Location:
    Brentwood, England
    Shooter:
    Multi Format
    Groups:
    I have TWO Epson flatbed scanners -- a 1650 which has a broken wire somewhere and scans with loads of coloured lines only and a 2480 with a smaller light in it and will scan only three 35mm frames against the 6 for the 1650 . i have some 'home-made masks' for Medium Format films,Now I seem to have strange 'scan lines' using the 2480 on medium format and 35mm . i HAVE cleaned the glass top and underneath but have not found the sensor to check if it is 'dirty' -- can anyone help me what is happening? I use 'Vuescan Pro' which a won FREE some years ago. I set 150 for 'pre-view' and 1600 for 'scan' . I attach some samples of scan lines ---
    Con Trails.jpg NPC160 05.jpg XA Rainbow.jpg
    The Medium Format is Fuji 160 NPC in Minolta Autocord, the Rainbow one is outdated Fuji 'Surveicolor 400 rated 200 ASA ' in Olympus XA

  2. Saganich

    Saganich Subscriber
    Ads Enabled

    Messages:
    736
    Joined:
    Nov 21, 2004
    Location:
    Brooklyn
    Shooter:
    35mm RF
    I think the overlooked question is if vuescan is functioning correctly. I've had some odd issues with updates in 2018 needing to revert to previous versions with older scanners. Might be good to try different software or older version of vuescan just to eliminate it as a variable.

  3. pentaxpete

    pentaxpete Subscriber
    Ads Enabled

    Messages:
    422
    Joined:
    Sep 23, 2010
    Location:
    Brentwood, England
    Shooter:
    Multi Format
    Groups:
    Oh Dear ! I've just 'upgraded' to the latest version 9.6.20 !

  4. shutterfinger

    shutterfinger Subscriber

    Messages:
    3,068
    Joined:
    Feb 25, 2013
    Location:
    San Francisco Peninsul
    Shooter:
    4x5 Format
    Those vintage scanners gas out and the residue that settle on the mirrors and lens cause the colored lines.
    Start a scan then pull the power cord from the rear of the scanner once it has moved a few inches from the home position. The scan block will now be positionable anywhere on the track until pushed back to the home position where it will lock. The scan block will return to the home position on next power up.
    Remove the bed, the cover over the lamp, the mirrors if possible. Clean the lamp, the mirrors, and the lens. They are on the front of the scan block.
    The sensor is on the rear of the scan block. DO NOT remove the sensor unless it is absolutely necessary to clean it.
    You will need a very good linearity target to scan to align the sensor on reassembly. The procedure is secure the sensor, install the bed, scan the linearity target, remove the bed, reposition the sensor, install the bed, scan the target until the scan is the same as the target.

  5. pentaxpete

    pentaxpete Subscriber
    Ads Enabled

    Messages:
    422
    Joined:
    Sep 23, 2010
    Location:
    Brentwood, England
    Shooter:
    Multi Format
    Groups:
    thanks -- i took off the cover again and cleaned the underneath of glass BUT I could not see any mirrors and scan lens -- it all 'seemed' dust free but I will try again .

  6. Ted Baker

    Ted Baker Member
    Ads Enabled

    Messages:
    197
    Joined:
    Sep 18, 2017
    Location:
    London
    Shooter:
    Medium Format
    I would not touch anything to do with the mirror, sensor or lens on these units. Unless of course you have decided its already dead. BTW is all in the little box that moves along, is just a little digital camera really :wink:

    The fact that you are seeing colour banding suggests to me at least this is hardware fault, or even software fault, not dust. But this is just a guess!

  7. shutterfinger

    shutterfinger Subscriber

    Messages:
    3,068
    Joined:
    Feb 25, 2013
    Location:
    San Francisco Peninsul
    Shooter:
    4x5 Format
    Once the cover on the carriage unit is removed ( 2 screws) the lamp and mirrors will be visible. All Epson scanners use the same basic build and disassemble similarly.
    The mirrors are front surface.
    I use microfiber lens cleaning cloth to clean the mirrors.

  8. nmp

    nmp Member

    Messages:
    489
    Joined:
    Jan 20, 2005
    Shooter:
    35mm
    There is indeed light reflected from the neighboring areas which introduces error in the measured value for a given spot. The amount of error is dependent on the luminosity of the neighboring areas. This is studied extensively by Doug Gray as presented at the Luminous Landscape forum:

    see for example: https://forum.luminous-landscape.com/index.php?topic=126590.msg1065018#msg1065018

    Just another complicating factor when any quantitative analysis is done on a scanner.

    :Niranjan.
