Neg scans (grain with FP4+)

Discussion in 'Scanning and Scanners' started by RalphLambrecht, Mar 1, 2018.

  1. RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    I know little about scanning B&W negatives; that's why i Had my FP4+ negs scanned by a pro-shop but, the results where horrid(grainy). Is that normal?

  2. Richard Man

    Richard Man Member

    Messages:
    707
    Joined:
    Sep 24, 2005
    Shooter:
    Multi Format
    Definitely not. Assuming your negs are with good exposure wise, FP4+ scans just fine... let me dig up some examples...

  3. Richard Man

    Richard Man Member

    Messages:
    707
    Joined:
    Sep 24, 2005
    Shooter:
    Multi Format
    Sorry, not an inspiring image or anything. I mostly shoot Tri-X on B&W but I know I shot some FP4+ last year. Unfortunately, I don't mark the film type on the neg sleeves so I just rummaged and found this. I haven't even scanned it in since it's not that great, but at least this serves as an example. This is done on a Flextight but I have used and owned MANY scanners and they should all scan decently.
    p.s. I offer scanning services. See my sig.


    Attached Files:

  4. Adrian Gabor

    Adrian Gabor Member

    Messages:
    41
    Joined:
    Jul 20, 2017
    Location:
    Earth
    Shooter:
    Multi Format
    You should show us some examples first.
    I find that in general people tend to underestimate how grainy film can be, especially coming from digital or even color negative.

  5. awty

    awty Subscriber

    Messages:
    372
    Joined:
    Jul 24, 2016
    Location:
    Australia
    Shooter:
    Multi Format
    What resolution did they scan at?
    Low resolution will show more grain.

  6. Svenedin

    Svenedin Subscriber

    Messages:
    1,062
    Joined:
    Mar 19, 2016
    Location:
    Surrey, United Kingdom
    Shooter:
    Med. Format RF
    I don't scan very often and I only have a flatbed Epson V800 (not a pro drum scanner) but the scans should not be "horrid". My scans (including FP4+) are not excessively grainy either. It sounds like the settings used were not optimal.

    This is an FP4+ scan, 35mm. You can see the grain but personally I don't think it's a problem. I used this scan as an example as it contains a lot of (blue, cloudless) sky. (this picture would look better with some of the superfluous sky at the top cropped out).


  7. Ted Baker

    Ted Baker Member

    Messages:
    164
    Joined:
    Sep 18, 2017
    Location:
    London
    Shooter:
    Medium Format
    Not sure what your normal is... :wink:

    A film scanner is not anywhere near capable of resolving the particles of silver on film, combine that with fact that many scanners use a technique called pixel shifting, along with re sampling and sharpening operations. Those last points combine with the natural patterns creates the grain pattern you see on the scan, and as you point out it is not necessarily the same pattern you would see on an optical print.

    So both physical sampling size of the sensor and the subsequent processing of the scan, will make a difference.

    For example drum scans can typically adjust the aperture size, and even though this is too large to actually resolve the particles, it does affect the appearance of the grain pattern in the image.

    Last edited: Mar 1, 2018
  8. Les Sarile

    Les Sarile Member

    Messages:
    1,986
    Joined:
    Aug 7, 2010
    Location:
    Santa Cruz, CA
    Shooter:
    35mm
    What scanner was used and post examples to show the grain as one person's horrid grain may not be so bad for others.
    Since it's b&w, you can visually verify if the film itself has horrid grain and whether the scan over exaggerated it or not.
    It's been my experience that all minilab scans tend to exaggerate apparent grain due to over sharpening and JPEG compression.

  9. jim10219

    jim10219 Member

    Messages:
    631
    Joined:
    Jun 15, 2017
    Location:
    Oklahoma
    Shooter:
    4x5 Format
    Most of the time, it's not grain that you see, but scanner noise. It's pretty hard to get actual grain in a scan, especially with consumer level equipment. And most film processing labs don't own high quality scanning equipment. They're using scanners built for high volume/high speed, so they're not spending all day doing a single roll of film. I can resolve the grain with my DSLR and a macro setup, but that requires magnification ratios so high that I'm having to stitch together multiple shots and files sizes in the gigabytes. It's not really worth the time or space.

  10. paulbarden

    paulbarden Member

    Messages:
    645
    Joined:
    Nov 12, 2014
    Location:
    Oregon, Willamette Valley
    Shooter:
    8x10 Format
    I used to get neg scans done at local shops, and I never got results that were as good as what I learned to do myself, once I bought an Epson V750.

  11. OP
    OP
    RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    they were exposed at godspeed and I would call them on the thin-side of perfect; there is no problem wet-printing them at grade 2.5!

  12. OP
    OP
    RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    I'd been very happy to get something such as this.

  13. OP
    OP
    RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    I'd post examples but the files are too big for APUG.

  14. Sponsored Ad
  15. OP
    OP
    RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    this looks fine;I'd be happy with that.

  16. OP
    OP
    RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    I'm not aware of the detailed technical details but gave the negs to another lab to get them scanned again.They are using an Imacon scanner;We'll see how this turns out.

  17. MattKing

    MattKing Subscriber

    Messages:
    22,923
    Joined:
    Apr 24, 2005
    Location:
    Delta, BC, Canada
    Shooter:
    Multi Format
    Resize them down to 800 pixels on the longest side.

  18. Richard Man

    Richard Man Member

    Messages:
    707
    Joined:
    Sep 24, 2005
    Shooter:
    Multi Format
    I use a Pakon for fast/bulk scan and the Flextight for high quality scan. The image I show is from Flextight since it's medium format and the Pakon only does 35mm. In any case, the FT obviously produces much more detailed scans with higher dynamic range but even on 35mm, the Pakon's scans hold up quite well against FT. In other words, if your negs print well enough, I think it was an operator error if the scans you got is too grainy.

  19. OP
    OP
    RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    OK 04240007.jpg

  20. Ted Baker

    Ted Baker Member

    Messages:
    164
    Joined:
    Sep 18, 2017
    Location:
    London
    Shooter:
    Medium Format
    Do you have a similar size crop made scanned from a print?

  21. Richard Man

    Richard Man Member

    Messages:
    707
    Joined:
    Sep 24, 2005
    Shooter:
    Multi Format
  22. OP
    OP
    RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    sorry, not yet.

  23. OP
    OP
    RalphLambrecht

    RalphLambrecht Member

    Messages:
    10,389
    Joined:
    Sep 19, 2003
    Location:
    K,Germany
    Shooter:
    Medium Format
    for what purpose?

  24. Richard Man

    Richard Man Member

    Messages:
    707
    Joined:
    Sep 24, 2005
    Shooter:
    Multi Format
    SInce you have problems uploading, and sending a crop of unknown size, I am offering to help to see if I can diagnose the problems, but never mind.

  25. Bob Carnie

    Bob Carnie Subscriber

    Messages:
    7,191
    Joined:
    Apr 18, 2004
    Location:
    Toronto-Onta
    Shooter:
    Med. Format RF
    I would first ask the lab this simple question,,,, Did they use sharpening when scanning and wait for the response... for all good quality work the sharpening should be turned off ... I have a Imocan and input sharpening at the scan stage is the kiss of death...

  26. Alan Edward Klein

    Alan Edward Klein Member

    Messages:
    267
    Joined:
    Aug 29, 2017
    Location:
    New Jersey, USA
    Shooter:
    Medium Format
