Weird, but at least its still something you can buy.

At some point I might have to just order a newer Intrepid head to make sure I'm wiring it all up correctly. But for any "adapter" it likely makes the most sense to just use screw/solder terminals and wire it up with whatever cable is requested.

Its a shame that neither of their chosen cables are friendly to just having an actual mount-able connector on the timer side.


tcolgate

Subscriber
Allowing Ads
Joined
Aug 28, 2025
Messages
43
Location
London
Format
Medium Format
Its a shame that neither of their chosen cables are friendly to just having an actual mount-able connector on the timer side.

They are very ver focused on that connection being water tight for some reason. Maybe its something they hut in a regulatory review, or just being ultra focused on it bein in super confined spaces with trays of liquid.? It is weird though. Its not super high current or voltage there and they could have had a connector straight into the LED head.
Still, in these circumstances I just assume they had a reason.


dkonigs

Subscriber
Joined
Sep 17, 2009
Messages
380
Location
Mountain View, CA
Format
Multi Format
They are very ver focused on that connection being water tight for some reason. Maybe its something they hut in a regulatory review, or just being ultra focused on it bein in super confined spaces with trays of liquid.? It is weird though. Its not super high current or voltage there and they could have had a connector straight into the LED head.
Still, in these circumstances I just assume they had a reason.

Its really hard to tell, given that there's absolutely nothing even remotely "water tight" about either their head or their timer. Or the power adapter's connection to the timer, for that matter.

It feels more like they didn't want to have a connector there at all, but it wasn't practical to have the two pieces permanently wired together.

Of course there's always concern about a cable being accidentally yanked out, especially when fiddling with the enlarger head. Maybe that's it.
