I ordered my enlarger... Low contrast lenses for 35mm negatives?

Discussion in 'Darkroom Equipment' started by Juan Valdenebro, Feb 9, 2018.

  1. Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    Hello,

    Finally I ordered a recent Kaiser 6x6 condenser enlarger, named 6005. It’s coming from Germany to South America, so it’ll take a few weeks…

    About my contrast worries: even if I thought I was going to buy a diffuse light enlarger, someone had a precise comment about condenser enlargers being better for just one thing: sharp grain prints (only type of prints I do)… So, I went for a condenser one in the last minute… Yet I’d like to “cure” my usual negative contrast a little bit while printing, and today I remembered an old darkroom teacher once told me “you should use an old lens instead of that Nikon, for a more gentle contrast…”

    Then, here I am asking again… (I couldn’t find a good thread on this…) I’d like to use, for 35mm enlarging, a good enlarging lens with clearly lower contrast (I push film) than my Nikon EL 50mm f/2.8, AND, I think I would prefer bigger prints at maximum height (nicer than floor/wall work…), so:

    Question 1: which 50mm, low contrast enlarging lenses would you recommend?

    Question 2: which slightly wider than 50mm lenses would you recommend for lowish contrast?

    Question 3: does using a lens wider than 50 imply any consideration “for all lenses” about light falloff or image circle for a 35mm negative? I imagine it depends on lens design… So, possibly, there are a few wider than 50mm lenses out there good for low contrast, and with good coverage of 35mm format…

    Thanks!

  2. chip j

    chip j Subscriber

    Messages:
    1,822
    Joined:
    Oct 26, 2012
    Location:
    NE Ohio
    Shooter:
    35mm
    Old Leitz Elmar enlarging lens--"DOOG".

  3. cliveh

    cliveh Subscriber

    Messages:
    5,451
    Joined:
    Oct 9, 2010
    Shooter:
    35mm RF
    If you want soft images why buy a condenser enlarger? A condenser will give you an inherently more contrasty image, hence sharp grain prints. You may have been better off buying a diffuser enlarger for what you are trying to achieve.

  4. michael_r

    michael_r Subscriber

    Messages:
    7,174
    Joined:
    Feb 2, 2010
    Location:
    Montreal, Canada
    Shooter:
    Multi Format
    Juan, I would not suggest using a low contrast enlarging lens. Instead I would suggest using a good lens, and variable contrast printing paper.

  5. Bob Carnie

    Bob Carnie Subscriber

    Messages:
    7,163
    Joined:
    Apr 18, 2004
    Location:
    Toronto-Onta
    Shooter:
    Med. Format RF
    I agree

  6. OP
    OP
    Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    Hi, this story comes from a previous thread... Yes, I use VC paper... I want a lower contrast lens after using VC paper with a condenser enlarger and well pushed film for many years... As others think, I can print my pushed negatives better with a bit less contrasty projected image... Thanks.

  7. OP
    OP
    Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    Hi, this story comes from a previous thread... Yes, I use VC paper... I want a lower contrast lens after using VC paper with a condenser enlarger and well pushed film for many years... As others think, I can print my pushed negatives better with a bit less contrasty projected image... Thanks.

  8. OP
    OP
    Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    Hi, I don't want soft images. Thanks.

  9. Paul Howell

    Paul Howell Subscriber

    Messages:
    3,725
    Joined:
    Dec 23, 2004
    Location:
    Phoeinx Ariz
    Shooter:
    Multi Format
    After many years, 55 going on 56, and have used Point Source, Diffusion and Condenser. By adjusting the grade of the paper you can match a print made on a diffusion head with a print made on condenser head, a point source head in my tests seems to be very different. Remember that "Condensers" head are really semi diffusion as they use frosted bulbs. With filters and VC paper or a range of fixed grade papers you ought to be just fine. Other factors is glossy vs matt or luster, warm tone vs cold tone, the developer as does the working aperture, say F2.8 or F8 can make a difference. I recommend a good quality 50mm, the prince point to some extent depends on the largest size you intend to print. Some lens were designed for very large prints and these lens will cost more as will APO design, which I recommend if you are going to print color. For up to black and white 11X14 a good quality 4 element will work just fine.

  10. Old-N-Feeble

    Old-N-Feeble Subscriber

    Messages:
    6,267
    Joined:
    Feb 22, 2012
    Location:
    South Texas
    Shooter:
    Multi Format
    You could also experiment with pre-flashing the paper... has a similar effect to shadow fogging through uncoated lenses. The plus side is that you can adjust the amount of pre-flash for each image rather than just taking what the lens has to offer.

  11. Jens Hallfeldt

    Jens Hallfeldt Member

    Messages:
    148
    Joined:
    May 30, 2017
    Location:
    Schaumburg, North Germany
    Shooter:
    Multi Format
    +1 Yes, so do I. A good and clear lens, unless mushy images are your goal.

    One more idea would be to use a low contrast paper developer like Tetenal Centrabrom S.
    And as Old-N-Feeble said, pre-flashing the paper. It works fine for me.

    Best
    Jens

    Last edited: Feb 9, 2018
  12. Svenedin

    Svenedin Subscriber

    Messages:
    1,062
    Joined:
    Mar 19, 2016
    Location:
    Surrey, United Kingdom
    Shooter:
    Med. Format RF
    I have a Kaiser VPM 7005 enlarger which is similar to yours but I have a multigrade head and can enlarge 6x7 negatives. Your enlarger is not a pure condenser enlarger. Yes it has a big glass condenser lens but it also has a diffusion box for the lamp so it is a hybrid diffuser/condenser enlarger. Use the best, sharpest lenses you can and alter the contrast using variable contrast filters and multigrade paper. I'm sure you will be happy with your results.

    PS: If you want big prints but are limited by the height of the enlarger column then look for WA (wide angle) lenses (for example, I sometimes use a Rodenstock 60mm WA for 6X6 where usually I would use an 80mm; likewise a 40mm WA where I would usually use 50mm for 35mm film).

    Last edited: Feb 9, 2018
  13. OP
    OP
    Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    Interesting... When I enlarged MF with my Rodenstock 80 (I don't remember which model: it's inside a big moving box yet) I got less contrasty prints (same enlarger, same paper, same filter, same developer and same complete paper development) than when I enlarged same contrast 35mm negatives with my Nikkor 50.
    If my Kaiser 6005 happens to produce as you say a type of light that's a bit more diffuse than the light my meopta opemus 6a produced, I would say that would be enough change and I don´t need a lower contrast lens...
    If not... Well, I can´t know right now...

  14. Sponsored Ad
  15. voceumana

    voceumana Member

    Messages:
    372
    Joined:
    Aug 4, 2004
    Location:
    USA (Utah)
    Shooter:
    Multi Format
    I think many photographers think lens contrast is the same as image contrast or subject contrast, and it is not. All lenses produce an image with lower contrast than the subject--whether that subject is a camera subject or a negative being projected. This is because all lenses have some amount of flare which reduces contrast.

    Enlarging itself further reduces contrast because of the flare involved in projecting the image--light bouncing around in the bellows, and other parts of the enlarger.

    Rather than crippling your equipment by using a lower quality lens, try using a softer working print developer such as Selectol-Soft. I believe the formula is published. If you want more flare to reduce contrast--a bad idea in my opinion--just put some dust on your lens since you can always remove it.

    One of the reasons contact prints looks so stunning is that there is little reduction of contrast of the negative on the paper.

  16. ic-racer

    ic-racer Member

    Messages:
    8,644
    Joined:
    Feb 25, 2007
    Location:
    Midwest USA
    Shooter:
    Multi Format
    When evaluating contrast in projection prints, realize that, in addition to hazy or fungal lens elements, there are many other sources of low contrast. Leaking safelights, reflected light from the baseboard, stray light in the bellows, non-image forming light hitting the lens (rebate and improperly masked images), wide apertures, etc, etc.

    Experimentation with low contrast and hazy enlarging lenses gives portraits a ghoulish appearance and landscapes take on a creepy appearance due to the shadow areas bleeding into the highlights. Might be good for pictures of a graveyard if that is what you want to do.
    Here is one I did with a low contrast enlarging lens which I like:

  17. chip j

    chip j Subscriber

    Messages:
    1,822
    Joined:
    Oct 26, 2012
    Location:
    NE Ohio
    Shooter:
    35mm
    NICE picture. Most old "DOOGS" will have many fine scratches on them.

  18. OP
    OP
    Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    I never talked about a lower quality lens... And I use soft developers too... Thanks.

  19. Hilo

    Hilo Subscriber

    Messages:
    489
    Joined:
    Apr 19, 2011
    Shooter:
    35mm
    Before using this enlarger I would not get any other lens. With a new-to-you enlarger things will be different from what you are used to. It always is. Just try this enlarger to see where it gets you. Also, going up in size like you describe will work in your favour as generally you would need a higher grade contrast filter. Just use low contrast filters.

    After that, yes, later lenses tend to give more contrast. So, Chip's suggestion to get a much older but reasonable quality lens is a good suggestion. But it remains to be seen if an older lens would solve your problem (if you have a problem). Often the differences between lenses are minimal.

    I wonder if, since you push film, you should just accept your negatives have a higher contrast and it will show in your prints. Nothing wrong with that.

    Last edited: Feb 9, 2018
  20. MattKing

    MattKing Subscriber

    Messages:
    22,874
    Joined:
    Apr 24, 2005
    Location:
    Delta, BC, Canada
    Shooter:
    Multi Format
    That appearance of lower contrast may be due to a number of factors, and may not represent an actual difference in contrast.
    Different cameras, different lenses, different films, different development and different magnification.

  21. jjphoto

    jjphoto Member

    Messages:
    310
    Joined:
    Oct 9, 2010
    Location:
    Melbourne, A
    Shooter:
    Multi Format
    Coatings on EL's have been pretty good for a long time, so you might have to use a lens from the 50-60's or so to get a softer lens (because of greater internal flare), without loosing too much in the way of resolution. Also, a six element lens will naturally flare more than a 3 or 4 element lens. The Kodak Enlarging Ektar from the 40's is (reputedly) an excellent lens but with very early coatings, it might be worth a shot as they are abundant and cheap.

  22. Bill Burk

    Bill Burk Subscriber

    Messages:
    6,027
    Joined:
    Feb 9, 2010
    Shooter:
    4x5 Format
    You already have a great lens don’t look for another. If you want a “better” lens you might find one but the one you have is going to work.

    To reduce contrast you could put a translucent sheet or opal glass under the condenser.

    You could reduce contrast by “filing” your negative carrier for black borders.

    To make murals from 35mm you might want a better lens like APO Rodagon-N but I think you’ll be ok with what you have.

  23. OP
    OP
    Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    Hello Matt, perhaps magnification... When I compared both of them, both were films I had calibrated already: exposed and developed (kodak´s gray card included in the frames) for the same negative contrast... I thought the difference in contrast on prints was because my MF Rodenstock lens wasn´t as contrasty as my Nikkor... But maybe magnification was relevant...

  24. OP
    OP
    Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    Hilo, Bill, I agree: why think anything before working with the new enlarger?... I'll wait and see... Thanks again.

  25. Svenedin

    Svenedin Subscriber

    Messages:
    1,062
    Joined:
    Mar 19, 2016
    Location:
    Surrey, United Kingdom
    Shooter:
    Med. Format RF
    @Juan Valdenebro I think you will love your new enlarger. It's very well made and solid. Logical, practical and modular. You can upgrade it in the future if you wish. Columns, baseboards, condensers and heads are interchangeable within the "System-V". Make sure you have the correct lens mounting rings. These are different for different focal lengths of enlarging lens. There is one for lenses less than 60mm focal length (part 4423) and another for lenses over 60mm (part 4424). Also make sure the lens mounting ring is attached to the enlarger the right way round (the markings face outwards). There is a quick release system so you can screw the lens into the mount and then mount on the enlarger. This also ensures the lens always has the aperture markings aligned at the front where you can see it. You will have tilt of both the head and the enlarging stage (Scheimpflug principle) so you can correct distortion due to camera lens tilt. There is a built in red filter and facilities for below or above lens filters (or dichroic continuously adjustable built in filters with a multigrade head).

    If you don't have instructions they are here: http://www.kaiser-fototechnik.de/en/service/anleitungen/4_3_index.asp

  26. OP
    OP
    Juan Valdenebro

    Juan Valdenebro Member

    Messages:
    78
    Joined:
    Jan 26, 2010
    Location:
    South America
    Shooter:
    Multi Format
    Hello Svenedin, sure it sounds well designed... Thanks for the information and link...
