Hey all,

I recently got a Mess Ikonta from Certo6 via ebay. It's a pretty nice camera, and I think I'll like shooting with it, but I have one problem with it, and wonder if it's something worth sending back to Jurgen for adjustment/repair, or is it one of those features that never really worked well and I should just work around it.

The problem I have is that anywhere from 30% to 60% of the time, the shutter release does not actually trigger the shutter. It isn't pushing the shutter mounted release far enough to trigger it. Strangely, holding the camera for a vertical shot makes it much less reliable than if it is held horizontally. It fires fine if I press the release directly with my finger. Not the most convenient thing, but a viable work-around for the very finicky remote shutter release. Not talking about the double exposure protection, I'm aware of that.

It seems like a pretty primitive and clunky mechanism, so I wouldn't be surprised if folks just bypass it.

What has been your experience? Should I expect this release to work dependably? Or should I just accept that it wasn't the best designed feature and work around it?

I haven't contacted Jurgen yet, just thought I'd find out your experience with this camera and whether this is a common problem.


jstout

Member
Joined
Apr 3, 2010
Messages
125
Location
NJ USA
Shooter
Multi Format
Keep sending them back until he sends you a good one. Caveat emptor.


Pioneer

Member
Joined
May 29, 2010
Messages
3,285
Location
Elko, Nevada
Shooter
Multi Format
Contact Jurgen. He will adjust it for you so that it works properly. He is a very reliable seller and stands by his cameras.

The shutter mechanisms on these folding cameras are often a bit finicky. They are trying to mechanically transfer the action of pressing the shutter on the top plate out to a lens/shutter mechanism sitting out on the end of a deployed bellows. This mechanism has to be sturdy enough to reliable transfer the mechanical action while also being engineered in such a way that they can fold up when the bellows is closed.

I will point out one thing you should be aware of that can cause problems. These cameras have a primitive form of double exposure prevention that usually blocks the shutter action until the film is advanced. If you forget to advance the film and then press hard on the shutter button expecting the shutter to fire, it can bend the rods and bars so they can no longer work reliably even when everything is done correctly. Once you do get your mechanism adjusted remember to advance the film and cock your shutter before pressing the shutter button.

OP
OP

LyleB

Member
Joined
Jan 21, 2010
Messages
376
Location
Lower Michig
Shooter
35mm
Thanks, yes I'm aware of the double exposure lock. This isn't the problem. The shutter release mechanism depresses, and moves as it should, it just doesn't move far enough to actuate the actual shutter lever, at least not reliably.

I'll go ahead and email Jurgen. Sounds like you guys think this should be a reliable mechanism.


ntenny

Member
Joined
Mar 5, 2008
Messages
2,312
Location
Portland, OR, USA
Shooter
Multi Format
I'm going to differ with the hive mind and say that this is within typical parameters for the Ikonta/Nettar family. The shutter linkage is a little fiddly and sometimes doesn't provide enough pressure. Of the two Nettars I use regularly, one almost always fires, the other maybe 70% of the time; but that one is a 6x6, and my hand is big enough to reach around and trip the shutter directly without changing the grip. That's unlikely to work on a 6x9 unless you have E.T.'s fingers.

Jurgen may know if there's an easy adjustment to tune the linkage slightly. You could also just tape a little shim in place to increase the amount of "push" fractionally.

-NT

OP
OP

LyleB

Member
Joined
Jan 21, 2010
Messages
376
Location
Lower Michig
Shooter
35mm
Well, I sent an email to Jurgen late last night. Got a reply this morning at 9 Am. He had a couple of suggestions I could attempt myself, but said to return it to him if they didn't work and he would repair it.

I spent about two minutes to try his suggestion (simple clockwise turn of the shutter - just a "smidge" as he instructed. I didn't think it had even moved, but I can now fire the shutter no matter what position the camera is in. About 20 to 30 fires without a single failure. I'm betting the problem is solved.

Thanks for your opinions. I just wanted to get back and let you know that Jurgen responded quickly, accurately diagnosed what was wrong via email, and offered an effective and simple solution.

Now I get to go out and do some playing. Unfortunately, the weather is supposed to be COLD here this weekend.

My opinion of Jurgen is "Good Guy".


pbromaghin

Subscriber
Joined
Sep 30, 2010
Messages
3,275
Location
Castle Rock, CO
Shooter
Multi Format
I have an Ikonta 6x6 and have had occasional trouble with that mechanism. If the lens/shutter doesn't completely lock on opening the paddle doesn't always match right with the trigger. I can imagine it could be a lot harder with the 6x9 simply due to the length. Good to hear it turned out well.

I almost bid against you for that camera, btw.


Pioneer

Member
Joined
May 29, 2010
Messages
3,285
Location
Elko, Nevada
Shooter
Multi Format
Well, I sent an email to Jurgen late last night. Got a reply this morning at 9 Am. He had a couple of suggestions I could attempt myself, but said to return it to him if they didn't work and he would repair it.

I spent about two minutes to try his suggestion (simple clockwise turn of the shutter - just a "smidge" as he instructed. I didn't think it had even moved, but I can now fire the shutter no matter what position the camera is in. About 20 to 30 fires without a single failure. I'm betting the problem is solved.

Thanks for your opinions. I just wanted to get back and let you know that Jurgen responded quickly, accurately diagnosed what was wrong via email, and offered an effective and simple solution.

Now I get to go out and do some playing. Unfortunately, the weather is supposed to be COLD here this weekend.

My opinion of Jurgen is "Good Guy".

I also think Jurgen is a good guy. :smile:


elekm

Member
Joined
Sep 12, 2004
Messages
2,055
Location
New Jersey (
Shooter
35mm RF
I was going to mention that you should rotate the lens/shutter assembly until the release lever on the side of the shutter is pressed against the small tab that is hinged to the lens door.

You do this by grasping the entire assembly firmly and turning to the right. But you have to be careful to not twist any other part, especially the struts that secure the lens door.


JPD

Member
Joined
Mar 24, 2007
Messages
1,520
Location
Sweden
Shooter
Medium Format
Nice that you could fix it yourself, LyleB.

I was going to mention that you should rotate the lens/shutter assembly until the release lever on the side of the shutter is pressed against the small tab that is hinged to the lens door.

You do this by grasping the entire assembly firmly and turning to the right. But you have to be careful to not twist any other part, especially the struts that secure the lens door.

Often you'll need to loosen the lens/shutter assembly retaining ring inside the bellows to do this, if it's tight, and then tighten it again after you have rotated the shutter.

OP
OP

LyleB

Member
Joined
Jan 21, 2010
Messages
376
Location
Lower Michig
Shooter
35mm
Nice that you could fix it yourself, LyleB.



Often you'll need to loosen the lens/shutter assembly retaining ring inside the bellows to do this, if it's tight, and then tighten it again after you have rotated the shutter.

Yeah, that was his second suggestion, if the shutter was too tight for a simple twist to work.

His third suggestion was to slightly bend the linkage on the camera body, but he cautioned that it would be difficult to do safely with out removing it first. He suggested that I send it back to him if that were required, and he would take care of it.
