x-ray film for enlarged negatives?

Forum statistics

Threads
198,521
Messages
2,776,524
Members
99,638
Latest member
Jux9pr
Recent bookmarks
0

davido

Member
Joined
Dec 15, 2005
Messages
575
Location
Toronto, Ontario, Canada
Format
4x5 Format
Hello

Has anyone tried using x-ray film for enlarged negatives for alt processes?
I have used APS lith as well as fuji scanner film with success, however, I am always on the look out for a film which can produce a full tonal scale without getting 'blocked up' in the mid-tones.
I'm wondering if X-ray film might be similar to lith or is it more similar to regular ortho film?

thanks
david


Whiteymorange

Subscriber
Joined
Jul 27, 2004
Messages
2,387
Location
Southeastern CT
Format
Multi Format
If you're looking for a copy film (negative to negative), X-ray ain't it. This is a negative film. Enlarging from a negative will give you a positive transparency. I just gave away my box of green sensitive 8x10 -- too little time, too much fiddling to get it to perform within the range of tones I needed. Others have had more success. The double emulsion built up density quite quickly and left me with harsh prints. Of course, if that's what your looking for...

I've heard that "extremity film" for hand xrays and mammogram film are single emulsion, fine detail film. I haven't tried 'em.


eworkman

Member
Joined
Nov 6, 2007
Messages
64
Location
Central Coas
Format
Med. Format Pan
Xrays are also duplicated, to get a neg from a neg and continuous tone [ as opposed to high contrast lith]
So get some Xray duplicating film- available from the medical folks or as "Continuous tone direct duplicating film" from Photowarehouse. The thread directly under this one will give you some hints as to developers , contrast etc. Short form, it's cheap enough to try in D 76 HC 110, Dektol etc to get it to do what you want. I have used it to dupe negs by contact, and have tried some projection dupes at larger size. Dense negs will make you crazy, normal or thin negs will just take long exposure; get a LOT of light that contains a lot of blue, or a calendar. Dupe film has a tendency to increase contrast, which you may find beneficial to your needs.


wclavey

Member
Joined
Apr 13, 2005
Messages
256
Location
Houston, TX
Format
Multi Format
X-ray film is very inexpensive. Why don't you just purchase a pack and try it out. It is not similar to regular ortho film, or lith.

Gene is absolutely right... and many of the X-ray film suppliers will send you several sheets to test with for free. You will learn a lot about it just from those few sheets.

OP
OP
davido

davido

Member
Joined
Dec 15, 2005
Messages
575
Location
Toronto, Ontario, Canada
Format
4x5 Format
Gene is absolutely right... and many of the X-ray film suppliers will send you several sheets to test with for free. You will learn a lot about it just from those few sheets.

Yes, I probably will give it a try. I'm not concerned about the price, it's the amount of time it takes one to experiment with a film such as this which comes with no instructions. Isn't that why these forums exists? To share information about unconventional techniques and products which don't come with an instruction manual, so that we can pool information and come up with new and creative means of producing our work.

-david

OP
OP
davido

davido

Member
Joined
Dec 15, 2005
Messages
575
Location
Toronto, Ontario, Canada
Format
4x5 Format
Xrays are also duplicated, to get a neg from a neg and continuous tone [ as opposed to high contrast lith]
So get some Xray duplicating film- available from the medical folks or as "Continuous tone direct duplicating film" from Photowarehouse. The thread directly under this one will give you some hints as to developers , contrast etc. Short form, it's cheap enough to try in D 76 HC 110, Dektol etc to get it to do what you want. I have used it to dupe negs by contact, and have tried some projection dupes at larger size. Dense negs will make you crazy, normal or thin negs will just take long exposure; get a LOT of light that contains a lot of blue, or a calendar. Dupe film has a tendency to increase contrast, which you may find beneficial to your needs.

Thanks eworkman. I had always wanted to try duplicating film but was put off by the price and now, I believe, it may not be available anymore? This x-ray duplicating film is quite exciting! On ebay it's very cheap! It's also coated only on one side.


-david


wclavey

Member
Joined
Apr 13, 2005
Messages
256
Location
Houston, TX
Format
Multi Format
Yes, I probably will give it a try. I'm not concerned about the price, it's the amount of time it takes one to experiment with a film such as this which comes with no instructions. Isn't that why these forums exists? To share information about unconventional techniques and products which don't come with an instruction manual, so that we can pool information and come up with new and creative means of producing our work.

-david

I absolutely agree! My point was that it didn't need to cost to experiment and to encourage people to try it! The only cost is their time. And the people here can even short-cut that by giving you their experiences as a starting point. Gene was EXTREMELY helpful to me a year ago or so on it. I can certainly share my learning, if anyone wanted it...

I did my original exploration & experimentation on blue sensitive high spped film, but based on what I have read here and over on LFPF, I have switched to medium speed green sensitive... bought a new box of that ...so I'm starting over.


eworkman

Member
Joined
Nov 6, 2007
Messages
64
Location
Central Coas
Format
Med. Format Pan
Xray dupe film is offered on several medical xray webstore sites.
Some of the info is not clearly stated on some sites, such as how many sheets in a box
Most seem to be 100 sheet boxes
I didn't go back to check Photowarehouse, but I'd bet 1.5 euros that they offer 25 and 100 sht packs- I buy 8x10 and recall that they have offered larger and smaller sizes- 11x14? 5x7?
14x17 dupe film is listed at National Discount Xray Supply - 25 sheets for $69.50

BUT Isn't lith film really slow also and doesn't it have an extremely narrow tolerance for exposure /development? If that's true and you have mastered lith, dupe should present you with a relatively easy learning curve, I'd opine. Hey if I can do it............

OP
OP
davido

davido

Member
Joined
Dec 15, 2005
Messages
575
Location
Toronto, Ontario, Canada
Format
4x5 Format
Thanks to everyone for their replies.
One other question:
Is x-ray duplicating film orthochromatic ie. can I use it under a red or amber safelight?

-david


Vaughn

Subscriber
Joined
Dec 13, 2006
Messages
10,074
Location
Humboldt Co.
Format
Large Format
David, most X-ray products are...for ease of handling by the techs under red safe lights.

vaughn


Larry Bullis

Subscriber
Joined
May 23, 2008
Messages
1,257
Location
Anacortes, WA, USA
Format
Multi Format
I've asked about x ray materials when getting x-rayed, and a technician once gave me some which I never got around to using. I recall, though, that she said that x ray materials are coated with emulsion on both sides. I don't know whether this is generally true, or just true of the materials they were using. However, if they are coated both sides, forget about critical sharpness.


Vaughn

Subscriber
Joined
Dec 13, 2006
Messages
10,074
Location
Humboldt Co.
Format
Large Format
There are some one-sided x-ray films...they have notches, whereas the two sided do not. And you seem to be correct about the sharpness of the two-sided, but it is not too bad. It will depend on the printing process. Simple contract prints onto silver gelatin paper were fine, as are platinum prints. A loss of sharpness seems to be there with carbon prints, but I need to try it again with a different negative to be sure.

Vaughn


PHOTOTONE

Member
Joined
Oct 30, 2006
Messages
2,412
Location
Van Buren, A
Format
Large Format
However, if they are coated both sides, forget about critical sharpness.

Common, inexpensive X-ray film is coated on both sides with emulsion. Theoretically this would limit resolution, as the image from a camera would only be focused on the one side, but in practice, the X-ray images are plenty sharp. If you normally shoot your images with your lens stopped down a couple of stops, the depth-of-field of the lens would compensate and would render both sides "in-focus". Otherwise the very-very slight out-of-focus of the back side of the film can be used as a creative tool, just like the blue, and or blue-green sensitivity of the films is used as a creative tool.


jeffreyg

Subscriber
Joined
Jun 12, 2008
Messages
2,632
Location
florida
Format
Medium Format
Use your regular bw film in what ever camera format you have. Then enlarge the negative on to x-ray duplicating film, ie Kodak dental x-ray duplicating film (8x10) with Kodak GBX chemistry. Other brands may be available in different sizes. The Kodak film is sharp as a tack, very slow and rather expensive but yields great results. remember that it is a reversal film so you do the opposite burning to lighten and dodging to darken the film - so when you print you get the reverse. You must use a red safelight. I use it for platinum/palladium contact printing.
Jeff


Jim_in_Kyiv

Member
Joined
Apr 7, 2005
Messages
231
Location
Ukraine
Format
Med. Format RF
I absolutely agree! My point was that it didn't need to cost to experiment and to encourage people to try it! The only cost is their time. And the people here can even short-cut that by giving you their experiences as a starting point. Gene was EXTREMELY helpful to me a year ago or so on it. I can certainly share my learning, if anyone wanted it...

I did my original exploration & experimentation on blue sensitive high spped film, but based on what I have read here and over on LFPF, I have switched to medium speed green sensitive... bought a new box of that ...so I'm starting over.


Interesting idea about using X-ray film and just what I needed; there's got to be plenty of it running about over here. Thanks!

It seems that "why don't you just try it", "what about 6x6cm instead" and "there was a good thread about this..." are important stock answers that need to be intoned frequently. "Just try it" has gotten me off my duff once or twice even though I wasn't the intended recipient.

One thing that I'd like to see more in general is the "here's the results" follow-ups to interesting threads like this.
What's new? Has it worked the way you wanted??

OP
OP
davido

davido

Member
Joined
Dec 15, 2005
Messages
575
Location
Toronto, Ontario, Canada
Format
4x5 Format
Interesting idea about using X-ray film and just what I needed; there's got to be plenty of it running about over here. Thanks!

It seems that "why don't you just try it", "what about 6x6cm instead" and "there was a good thread about this..." are important stock answers that need to be intoned frequently. "Just try it" has gotten me off my duff once or twice even though I wasn't the intended recipient.

One thing that I'd like to see more in general is the "here's the results" follow-ups to interesting threads like this.
What's new? Has it worked the way you wanted??

Jim, I can relate to your comment about 'follow up'. I will do my best. As of the present moment: I have just purchase some Fujifilm MI-Dup 12x20 off of Ebay. I hope to use dilute HC-110 for developer, as this is what I have been using for my APHS lith negs. The GBX developer sounds interesting, does anyone know what it might be similar too?
I will keep the thread informed of my developments.

-david


DannL

Member
Joined
Jan 11, 2006
Messages
586
Location
Oklahoma
Format
Multi Format
. . . The double emulsion built up density quite quickly and left me with harsh prints. Of course, if that's what your looking for...

fyi, Yesterday while experimenting with Kodak MXB and MXG films, both of which have emulsion on both sides, I noticed you can easily remove the emulsion from either side of the film using a soft brush and common laundry bleach (ie; Clorox bleach).The process is almost immediate and does not appear to harm the base material. It's an incredible transformation of the film's capability, I must admit.

When using the film in a camera I would suggest noting which side of the film was facing the lens prior to reducing a specific side.


DannL

Member
Joined
Jan 11, 2006
Messages
586
Location
Oklahoma
Format
Multi Format
Did you remove the emulsion after the film was already expose, or developed?

I think I have perfected the process today.

Expose, develope and wash your x-ray film as normal. Once the film has thoroughly dried, place the film on a clean sheet of glass with your favorite side facing the glass. I am using a sheet of glass that is 14x18 for a film that is 8x10. Tape the film to the glass along the edges with 3M Scotch Safe Release Painters' Tape. Seal all edges of the film completely to insure no liquids can pass to the emulsion beneath. Use plenty of thumb pressure on the tape to insure a good tight seal. I double tape the corners, also. Using a soft 2" paint brush apply Clorox bleach to the surface of the film. Apply the bleach to the entire surface of the film in a brisk circular fashion. Continue this operation for about 15-30 seconds for the entire surface of the film. Wash the bleach off with water to see the results. Remove the tape and rewash the film.

If anyone would like to add their own experience here, please do.

Last edited by a moderator:

Brian Bullen

Member
Joined
Jun 26, 2004
Messages
160
Location
Twin Cities,
Format
Large Format
DannL I'm not sure why you are removing one side of the emulsion? Was there a defect or some other issue? So far I've had excellent results with a double sided film like konica ppg and kodak t/mat l-ra, also the density range of these negatives are perfect for pt/pd. I have printed on silver gelatin as well and sharpness has never been lacking, even on palladium which tends to look less sharp than silver.
Why go to all the trouble and risk damaging the negative? Does this help in an enlarged neg in some fashion?

Here is an example of an 8x10 x-ray neg printed with palladium.


Attachments

  • katekarenpd.jpg
    84.1 KB · Views: 327

DannL

Member
Joined
Jan 11, 2006
Messages
586
Location
Oklahoma
Format
Multi Format
That's an excellent photo, Brian. I can see you have devised a method that odviously works great.

As far as defects, yes. I've tried both tray and drum developing, and in either case one side of the emulsion ends up damaged. I prefer drum processing, but it is hard on the soft emulsion layer that is facing the inner drum wall. It can also leave bromide drag marks on that side of the film where the developer cannot circulate. But then it dawned on me . . . I have no need for emulsion on both sides of this film. Nor can I see the advantage to printing through a "double negative". So, I'm removing one negative layer, the layer that was originally facing away from the taking lens, and utilizing the remaining negative as a normal single-sided negative. So far it has worked like a champ. The day it causes me any grief, I'll make notice.


Brian Bullen

Member
Joined
Jun 26, 2004
Messages
160
Location
Twin Cities,
Format
Large Format
Thanks for the compliment and also for the insight on your process.
Scratches can be a concern, I have only tray developed 11x14 (8x10 in hangers and tank)but I did find that if I used a larger piece of film to cover the bottom of the tray my scratches were pretty much eliminated. Of course anything smooth to cover the bottom would work just as well.

I imagine drum processing would be near impossible with 2 sided film.Are you using straight bleach?


DannL

Member
Joined
Jan 11, 2006
Messages
586
Location
Oklahoma
Format
Multi Format
. . .
I imagine drum processing would be near impossible with 2 sided film.Are you using straight bleach?

Clorox bleach, straight from the bottle. It doesn't take as much as one would imagine. Probably less than 1/8 oz.

OP
OP
davido

davido

Member
Joined
Dec 15, 2005
Messages
575
Location
Toronto, Ontario, Canada
Format
4x5 Format
following up

hello

I ran across this thread accidently and realized that I had never followed up with my results with MI-DUP. I had promised! oops.
I tried HC-110 dilution 1:14 stock and was getting nowhere fast. I ended up with dektol straight (which is what we used to use in school with lith film). This film needs a strong developer and agitation. It also needs long exposures. I am shooting almost wide open at around 6 or 7 minutes!! CRAZY! Of course, I was enlarging from a colour negative, which I'm sure added to the time.
However the results are extremely inspiring! It makes sense that this film needs so much exposure and development as it is made for dentists/doctors to make dupes and therefore it shouldn't be finicky to process. I would be much easier to use as a straight dupe film in a contact frame in daylight; I need to boost up my enlarger head with a stronger light source! Any ideas?
This film is such a refreshing change from lith film, which can be exacerbating to say the least!! I will definately be using this more in the future. I might even try it in camera (my new 8x10) though it might prove to be too low contrast.

david
