Platinum printing and the use of fumed silica

Fantasyland!

D
Fantasyland!

  • 7
  • 1
  • 59
perfect cirkel

D
perfect cirkel

  • 2
  • 1
  • 111
Thomas J Walls cafe.

A
Thomas J Walls cafe.

  • 4
  • 5
  • 207

Recent Classifieds

Forum statistics

Threads
198,743
Messages
2,780,191
Members
99,690
Latest member
besmith
Recent bookmarks
0

Klainmeister

Member
Joined
Jun 2, 2010
Messages
1,504
Location
Santa Fe, NM
Format
Medium Format
We look forward to seeing your results, Robert.

As for Fool's Gold--the developer is pretty straight forward and acts just like Gold, hence the name. With Kallitypes, Athenatypes and the like, you should get pleasing results and a quarter the cost. Good luck.

Edit: also, Bostick and Sullivan have fumed silica on hand at a great price as well, plus they can help you out on the phone with any questions. Feel free to call them up for supplies. Not trying to be a promoter, but I know the stuff there is pure, and the Amazon stuff makes me nervous when applying my time and serious $$$ to prints.

Edit edit: Barry, please post your results with the VanDyke. We have discussed it briefly (I'm a believer in VD but others aren't so enthusiastic) and haven't had to time to test. I would love to know how it goes.

Last edited by a moderator:

Barry S

Member
Joined
Jan 28, 2007
Messages
1,350
Location
DC Metro
Format
Large Format
Kyle--I'll be happy to post my VDB results. I recently placed a large order with B&S and was going to get the silica, but I got confused by the online catalog listing (dry, aqeous?) and forgot about it. I have the order from Robert's Amazon source on the way and am looking forward to testing. I think VDB looks amazing when the density is good and can't wait to see how the FGS toner works.


Loris Medici

Member
Joined
Sep 13, 2005
Messages
1,154
Location
Istanbul, Tu
Format
Multi Format
Haven't actually printed on it (will be back to printing not before next week...) but out of curiosity, I coated a paper with hydrophilic fumed silica (brand name: Aerosil 200) using an ordinary foam brush. The coating procedure was simple and effective (thanks for the visuals - helped a lot!), my only complaint would be about airborne particles - I didn't like that... The coating changes the feel of the paper considerably, but I liked it as it was. I later brushed water on it and haven't noticed any unusual brush drag / uneven absorption or something. Will try with real sensitizer soon...

Thanks,
Loris.

OP
OP
Robert Hall

Robert Hall

Member
Joined
Aug 18, 2004
Messages
2,033
Location
Lehi, Utah
Format
8x10 Format
Thanks for sharing that Loris, I think you will find the results dramatic. I was also concerned about airborne particles but I think you can make the "liquid" version by making a 4% solution with FS and distilled water. (Distilled just to eliminate other possible variables)

I didn't notice brush drag either and I have not yet tried the coating rods, but did find on the first couple that I had to be more careful of my brushing for evenness.


Klainmeister

Member
Joined
Jun 2, 2010
Messages
1,504
Location
Santa Fe, NM
Format
Medium Format
The powder form can definitely be irritating and we recommend the use of a simple mask during application times (as well as a large surface area to spill onto). The good news is that this stuff is used in toothpaste, milkshakes, etc as a thickening agent and hasn't been shown to be harmful.

Barry: super excited! I love well done Vandykes as well so this is exciting for me. I'll also try to post new development as they are discovered. Dick was very pleased to see the use of fumed silica outside our lab. Good work everyone!

Joined
Dec 10, 2009
Messages
6,297
Format
Multi Format
I've looked it up on the internet and it's used a thickening agent and anti-caking in food? Other than it's an inhalation hazard, I assume it's not toxic?


Barry S

Member
Joined
Jan 28, 2007
Messages
1,350
Location
DC Metro
Format
Large Format
It's not toxic, but it's unquestionably a respiratory irritant. I wear a respirator when using it and highly recommend the same for anyone else.


Klainmeister

Member
Joined
Jun 2, 2010
Messages
1,504
Location
Santa Fe, NM
Format
Medium Format
Throw on a bandana or a respirator and you should be fine. We have been using it with and without and I personally haven't experienced any irritation, but it was a big open space with calm air.


Barry S

Member
Joined
Jan 28, 2007
Messages
1,350
Location
DC Metro
Format
Large Format
I received my new fumed silica today and tried a few quick and dirty VDBs. I treated sheets of Revere Platinum and Fabriano Artistico with the silica and double-coated with VDB. I also tried the Fools Gold toner. I found I only needed to expose my neg for half as long as usual, but the results were a bit muddy--not sure I gained any dmax from the silica. It may have been the neg I chose--probably too flat, but I grabbed what was handy. The Fools Gold toner cooled off the prints fairly quickly (~5 minutes to medium brown), but also seemed to bleach them. I should get some density back in dry down, but it's all too preliminary to say much.


sharperstill

Member
Joined
Apr 21, 2008
Messages
147
Format
Large Format
I've bought some fumed silica from B&S and will try it shortly.
I thought I bought the powdered variety but it arrived as a liquid.

I've read Richard Sullivan's PDF and several threads but have not read a description of using the liquid form of fumed silica.
Should it be used neat?
How much should I use? (I'm printing 5x7 Pt/Pd on Arches Platine)
I assume I have to dry it before sensitising.

Any thoughts/experiences on the liquid stuff?

Jon


Klainmeister

Member
Joined
Jun 2, 2010
Messages
1,504
Location
Santa Fe, NM
Format
Medium Format
If you're doing wet, simply add just enough (kinda like adding your sensitizer to the paper) and roll it evenly passed the edges. I don't recommend brushes due to streaking. Go ahead and use a hair dryer or something similar to dry it out quickly and go ahead and add your sensitizer and expose as you normally would.

That should work.


Loris Medici

Member
Joined
Sep 13, 2005
Messages
1,154
Location
Istanbul, Tu
Format
Multi Format
Robert, I did 3-5 more trials:

- I get great dmax!
- There's considerable contrast increase; very nice in the shadows but sucks in the middletones and highlights!
- I get increased nap which isn't that good - shows as grain in the print... (I use a very thin paper - Masa - BTW; this may not apply to stronger papers with hard sizing.)
- It's hard to inhibit streaks. (Both due uneven application of silica fume and - eventually - coating solution.)
- I also mixed a ~ 10% (missed your 4% suggestion below...) suspension. Somehow, the wet application increase silica coating's unevenness - but could be because my suspension is too strong. Will investigate more on this...

I'll struggle some more but I feel like I won't use this technique with Masa paper. Will try with COT 320 or Fabriano Artistico later. (I'm also planning to add some into gelatin sizing solution for gum printing; maybe it can help in taming extra slick papers...)

That's all for now.

Regards,
Loris.

P.S. I try it with trad. cyanotype, on Masa paper.


Thanks for sharing that Loris, I think you will find the results dramatic. I was also concerned about airborne particles but I think you can make the "liquid" version by making a 4% solution with FS and distilled water. (Distilled just to eliminate other possible variables)

I didn't notice brush drag either and I have not yet tried the coating rods, but did find on the first couple that I had to be more careful of my brushing for evenness.

Last edited by a moderator:
OP
OP
Robert Hall

Robert Hall

Member
Joined
Aug 18, 2004
Messages
2,033
Location
Lehi, Utah
Format
8x10 Format
Loris,

Awesome results. I would agree, probably better for heavier paper. One might use FS as something to turn a surface matte. It might be used for something like albumen if you wanted a less glossy surface.

Post some images!

R

Joined
Jul 21, 2003
Messages
583
Location
Philadelphia
Format
8x10 Format
I haven't been to Apug in a while and didn't see this thread about the fumed silica before I started playing with it.

I made a blog post today comparing the fumed silica on Platine and Revere Platinum.

I bought the liquid from Bostic and Sullivan, and that works great on the Revere Platinum, but Robert mentioned that brushing/rolling on dry might work better with Platine. It will be a while until I can get my hands on some dry fumed silica and a few more papers to test, but I hope to follow up with it in a few weeks.

Here is a link to the write-up I did with a few pictures with side by side comparisons.

http://richardboutwell.wordpress.com/2012/03/26/platinumpalladium-printing-with-fumed-silica/


Davec101

Member
Joined
Jul 29, 2005
Messages
1,216
Location
Cambridge, U
Format
Large Format
Has anyone got some accurate reflective densitometer readings i.e Dmax values from using fumed silca, if so can you post them with pictures etc... Also does anyone know FS effect on the archival properties of a platinum/palladium print.

thanks

Last edited by a moderator:

Loris Medici

Member
Joined
Sep 13, 2005
Messages
1,154
Location
Istanbul, Tu
Format
Multi Format
Richard thanks for the report (haven't read it in depth - I'm at work right now, will return to it later...) & visuals. One quick comment: The zoom image shows more fibers (= "less absorption?" and "increased nap?") and is a little bit more grainy (at micro-scale) in the scan. This conforms with my experience; application of the amorphous silica onto the paper - somehow - do physical damage to the fibers / surface. One has to be very gentle with fumed silica. (Moreso with thin / delicate papers - at least in my experience...)

Regards,
Loris.


sharperstill

Member
Joined
Apr 21, 2008
Messages
147
Format
Large Format
OK, I finally got around to popping my fumed silica cherry last weekend. My views follow:
I used the wet version as supplied by Bostick + Sullivan.
I first printed an image on Arches Platine (the paper I am using somewhat reluctantly for a large ongoing project) without using any fumed silica. Once I got an acceptable image I coated another piece with fumed silica by way of a coating rod (same as I coat sensitiser). As a starting point I used 12 drops of fumed silica over an area about 6x8 inches (for neg size 5x7).

The coating went fairly well, except that I couldn't see anything. By looking at an angle I was able to determine what was wet and what was not. Three or four passes max and it looked like a good even coating. The paper was let sit for a few minutes then dried with a cool blow dryer.

I then coated and exposed the paper exactly as for the previous print. As per expectations I observed an increase in Dmax, a slight overall contrast increase (though less than I had expected). So it all seemed good. Who wouldn't want more Dmax with Platine, although I agree with someone else's comment (can't remember whose) about the extra highlight contrast being undesirable in some images. I did notice some of what I think Loris is referring to when she says "raised nap", although I've always found this to a degree with Platine and sometimes 'spot it' in darker areas.

I then tried another negative (4x5) and got very similare results although I noticed that an uneven coating of fumed silica results in patches or streaks of uneven Dmax, which looks crap.

I then tried another paper that a friend had been told worked well for platinum. He had never tried it so I took one for the team. Strathmore 500 series plate finish. Quite thin, about 120-130gsm I imagine. Not quite as white as platine but with a smoother finish. The first sheet creased from being too wet. I halved the drop count and coated again.

This is where it gets interesting, and frustrating. The first two prints, barring a few small areas of patchy Dmax, were stunning. To the point where I instantly had to consider re-printing my 4 year project. The Dmax was as good as platine or better, low separation and mid-tone contrast were better, and the image was sharper with 0 raised nap. It made the print on platine look quite ordinary.

Then, to overcome the patchiness in the fumed silica coat my friend suggested we coat the whole sheet. We did so, and it did not crease too badly as it was all wet, rather than a wet rectangle in an otherwise dry sheet.

This print looked terrible. There was barely a latent image, and when developed it looked flat and underexposed by about 3 stops. I figured I must have stuffed up the mix and tried again.

The next three prints were all the same, flat, pale and lifeless. Was it coating the whole sheet? One last print where I coated just around the image area as before. Same result, well slightly better see attached image. The earlier print is on the right, the problem print on the left. Same mix, same chemistry, same exposure unit and time, same developer. It's got me buggered. Since its dry the dud print also has a distinctly powdery feel to it which is absent on the other prints that worked. My apologies for the crappy phone pics, my scanner is packed away due to renovations.

I didn't get time to re-try with platine to check my process and I'm dumbfounded as to what happened or what changed. If it were repeatable the results I got on the Strathmore paper with fumed silica would force to consider re-printing my whole show.

Jon


Attachments

  • Lucinda.jpg
    302.4 KB · Views: 192

sharperstill

Member
Joined
Apr 21, 2008
Messages
147
Format
Large Format
Oh, forgot to ask. Has anyone mixed the fumed silica into the sensitiser and coated it all at once?


Dan Dozer

Subscriber
Joined
Dec 10, 2004
Messages
411
Format
Large Format
Resurrecting this thread for a little while - I got the liquid from B&S a while back and have finally gotten around to trying it out. Rolled it on with a foam roller as the directions say. Used it on both COT 320 and Revere heavy weight so both papers were pretty thick.

It did not roll on as directions said (until the sheen goes away!), but did appear to go on evenly. However, when printing, did not get anything like I expected. Had significant problems with added grain appearance and even bad spotting as well as blotchiness. Did not experience darker Dmax either.

I have no desire to waste any more of my expensive paper on this stuff. Perhaps the drier air here in the Desert has something to do with it, but I don't think so. Maybe the dry version would work better, but I'm not sure if I even want to try it out.

Has anyone else had similar problems with the liquid silica?


dpurdy

Member
Joined
Jun 24, 2006
Messages
2,673
Location
Portland OR
Format
8x10 Format
I spent the last few days printing with the dry silica. I found it easy enough, a bit of a learning curve on how much to use and how to spread it.
I couldn't see much difference at first using my old Cranes cover paper. But after looking at it awhile on a few different prints I see that it does have better dmax and better contrast in the blacks. It also has the affect of reducing the sheen on the paper after the print is dry so that it looks contrastier and clearer.
I was surprised how little powder it takes and also surprised that you can still feel it on the surface even after printing processing and washing.

I also got some of the liquid from B&S and the little foam roller they suggest. My first try it seemed very difficult to get on evenly and I got a bunch of bubbles on the surface. The dry is so easy that I think I will stick with that. I do like what it does. At least on the Cranes paper it gives better contrast in the lower tones and it prints very smoothly. I don't see a color change or a printing speed change.
Dennis
