Nikon Coolscan 9000: odd gradient on scans

Discussion in 'Scanning and Scanners' started by Tom Kershaw, Oct 29, 2018.

  1. Tom Kershaw

    Tom Kershaw Subscriber
    Ads Enabled

    Messages:
    3,061
    Joined:
    Jun 5, 2004
    Location:
    South Norfolk
    Shooter:
    Multi Format
    I've seen this crop up on some of my scans recently. Darkroom prints from the negatives are completely free of this gradient marking so logic suggests something is going wrong in the scanning stage. I'm using VueScan, but dug out an old computer and repeated scans with Nikon Scan 4 software which showed the same problem but to a lesser extent. Using the glass negative carrier and suspect something may be not operating correctly with how the holder is keeping the film flat. Has anyone else seen this?



    Tom

  2. manualcrank

    manualcrank Member

    Messages:
    8
    Joined:
    Feb 21, 2009
    Shooter:
    Multi Format
    I think this is caused by internal flare. I see it on overdeveloped/high-contrast negatives and sometimes when I don't use masking strips. Scan a properly exposed and developed negative of a flatly-lit scene to confirm.

  3. manualcrank

    manualcrank Member

    Messages:
    8
    Joined:
    Feb 21, 2009
    Shooter:
    Multi Format
    When it started happening to me I checked my thermometer. Turns out it I was developing everything at 26 C instead of 20. Problem went away after I replaced it.

  4. shutterfinger

    shutterfinger Subscriber

    Messages:
    3,066
    Joined:
    Feb 25, 2013
    Location:
    San Francisco Peninsul
    Shooter:
    4x5 Format
    Scanners pick up very slight differences in densities that do not show up in wet printing. Sometimes those differences are from insufficient fixing, insufficient washing, or haze in the atmosphere.
    Try putting the negative in the holder 180° and scan it again. Stripe on the same side of the viewed image its the scanner, stripe on the opposite side of the viewed image its the negative.

  5. gorbas

    gorbas Subscriber
    Ads Enabled

    Messages:
    640
    Joined:
    Dec 9, 2007
    Location:
    Vancouver, Canada
    Shooter:
    35mm Pan
    +1
    Most likely light leak around edges of glass carrier mask. On your scan I can almost see that square cut out on the left side of the mask?

  6. Oren Grad

    Oren Grad Member

    Messages:
    1,112
    Joined:
    Feb 17, 2005
    Shooter:
    Large Format
    And another +1.

  7. Patrick Robert James

    Patrick Robert James Subscriber
    Ads Enabled

    Messages:
    1,584
    Joined:
    Jul 31, 2012
    Shooter:
    Med. Format Pan
    You probably need to check to see if the mirror is dusty. That will cause flare around anything dark like the edge of the neg. Nikon scanners are infamous for it.

    I try to remember to clean my Nikon once a year at least but I often forget until I notice issues like the one you have.

  8. OP
    OP
    Tom Kershaw

    Tom Kershaw Subscriber
    Ads Enabled

    Messages:
    3,061
    Joined:
    Jun 5, 2004
    Location:
    South Norfolk
    Shooter:
    Multi Format
    Good point, the negatives were fairly dense / high contrast scenes.

    - this may be the case, I should read up on the mirror.

  9. EdSawyer

    EdSawyer Member

    Messages:
    1,598
    Joined:
    Sep 3, 2008
    Shooter:
    Multi Format
    Are you using the masks/strips to cover up the blank spots between frames?

  10. jtk

    jtk Subscriber
    Ads Enabled

    Messages:
    1,541
    Joined:
    Nov 8, 2007
    Location:
    Albuquerque, New Mexico
    Shooter:
    35mm
    A reminder to keep the scanner dust-covered when not in use. But in this case it does look like what happens with a waaay-too-dense negative. I doubt that problem would happen with a properly processed neg of a subject on a brightly lit white background or a bird in bright sky

  11. OP
    OP
    Tom Kershaw

    Tom Kershaw Subscriber
    Ads Enabled

    Messages:
    3,061
    Joined:
    Jun 5, 2004
    Location:
    South Norfolk
    Shooter:
    Multi Format
    Yes.

    Definitely a reminder. I've just scanned a negative with a more typical density (not over-exposed), photographed in bright sunlight and no sign of the problem. Think I'll hold off dismantling the scanner for the time being and monitor if and when this artefact occurs.

  12. jtk

    jtk Subscriber
    Ads Enabled

    Messages:
    1,541
    Joined:
    Nov 8, 2007
    Location:
    Albuquerque, New Mexico
    Shooter:
    35mm
    I think it's risky practice ever to open the scanner to attempt cleanings unless evidence demands that. If necessary it indicates the scanner lives in a dirty / dusty environment... This isn't a "notorious" Nikon reality, it applies to cameras and darkrooms for the same reasons. Occasional wet mopping of work environment is a good idea, frequent sweeping/dusting is a bad idea, dogs cats have to hang out elsewhere.

  13. OP
    OP
    Tom Kershaw

    Tom Kershaw Subscriber
    Ads Enabled

    Messages:
    3,061
    Joined:
    Jun 5, 2004
    Location:
    South Norfolk
    Shooter:
    Multi Format
    Thankfully the scanner is not in a heavily trafficked area. Good point on the wet mopping though.

  14. EdSawyer

    EdSawyer Member

    Messages:
    1,598
    Joined:
    Sep 3, 2008
    Shooter:
    Multi Format
    These are pretty easy to open and clean the mirror or lens, just an FYI. You can add flocking to the bottom panel as well, at the same time, which should cut down on light bouncing around inside.
