Perhaps an overdue addendum to my original post. I wanted to run a roll of color film though this camera, but got distracted by other projects, work, etc.

Anyway, I did get back to it and ran a roll of Provia 100F though my Chevron. My original handling comments remain, however, that Ektar lens sure does not disappoint.

View attachment 309442

View attachment 309443

View attachment 309444

View attachment 309445

View attachment 309446

View attachment 309447

View attachment 309448

View attachment 309449

Fantastic. Do you have higher resolution scans, that you could crop from, so we could get a feel for the resolution?

OP
OP
Hunter_Compton
Joined
Nov 20, 2019
Messages
102
Location
Oxford, MI
Shooter
Analog
Fantastic. Do you have higher resolution scans, that you could crop from, so we could get a feel for the resolution?

Yes, unfortunately I have to resize my scans to fit the upload limits here. Full sized .TIFF scans for my Chevron can be seen here: https://flic.kr/s/aHsmU6HzYz

Also, here's a 100% crop of the seventh image at 3200 PPI. This was shot at f/5.6 according to my notes as the building was shaded. We may reach the limits of my scanner before we can outresolve the lens though, as it's only an Epson V500 flatbed.



Paul Howell

Subscriber
Joined
Dec 23, 2004
Messages
7,352
Location
Scottsdale Az
Shooter
Multi Format
I was following OP post which stated it did.

The camera is fitted with a Kodak Ektar lens with a focal length of 78mm and a maximum aperture of f/3.5. The lens is a four-element unit focusing Tessar design. It is constructed of high quality optical glass containing Thorium Oxide which has optical properties of high refractivity and low dispersion

OP
OP
Hunter_Compton
Joined
Nov 20, 2019
Messages
102
Location
Oxford, MI
Shooter
Analog
I was following OP post which stated it did.

The camera is fitted with a Kodak Ektar lens with a focal length of 78mm and a maximum aperture of f/3.5. The lens is a four-element unit focusing Tessar design. It is constructed of high quality optical glass containing Thorium Oxide which has optical properties of high refractivity and low dispersion

Paul, did someone's post get deleted? To clarify since you asked about the Medalist in particular, the Medalist lens (at least my Medalist I) has no thorium, the Chevron does use Thoriated glass.


Paul Howell

Subscriber
Joined
Dec 23, 2004
Messages
7,352
Location
Scottsdale Az
Shooter
Multi Format
This is what said, more of a question.

"I don't believe the Medalist lens had a thorium element?"


Helge

Member
Joined
Jun 27, 2018
Messages
3,044
Location
Denmark
Shooter
Medium Format
Yes, unfortunately I have to resize my scans to fit the upload limits here. Full sized .TIFF scans for my Chevron can be seen here: https://flic.kr/s/aHsmU6HzYz

Also, here's a 100% crop of the seventh image at 3200 PPI. This was shot at f/5.6 according to my notes as the building was shaded. We may reach the limits of my scanner before we can outresolve the lens though, as it's only an Epson V500 flatbed.

View attachment 309464 View attachment 309465

Still gives a pretty good view of apparitions and side sharpness.
Thanks.
Looks like a superb lens.
