How to adjust/calibrate the Canon F-1 meter?

Beach walkers

A
Beach walkers

  • 0
  • 0
  • 21
Romy

A
Romy

  • 2
  • 1
  • 25

Forum statistics

Threads
204,410
Messages
2,868,143
Members
102,255
Latest member
brianalog
Recent bookmarks
0

BHuij

Subscriber
Joined
Oct 12, 2016
Messages
989
Location
Utah
Format
Multi Format
I have done diode modifications to my Olympus OM-1 and Canon FTb so I could use SR-44 batteries in them. The Olympus had a cam inside that I could adjust until the meter matched my "source of truth" spotmeter at all relevant EVs. The FTb had a set of 3 potentiometers under the top plate that served the same purpose. Both are now within 1/3 stop of my spot meter, and have produced several rolls with fantastic results relying on those meters.

I recently purchased my grail SLR, a Canon F-1n, in really fantastic condition. While I'm undecided on a diode modification there, and am currently just using 675 zinc air batteries, I find its meter doesn't agree very closely with my spot meter in most cases. My Google-fu has not turned up much of anything helpful. Anyone know what the procedure is for adjusting the meter on the F-1n (not the New F-1, to be crystal clear).
