Emily Cook

Member
Joined
May 1, 2026
Messages
6
Location
California
Format
Multi Format
Hello from the California central coast! I’m not very good at online social stuff and there’s a good chance I’ll mostly just lurk here, but I figure I can put together an intro at least.

Among other things I’m a mom in my 40s, an FPGA signal processing engineer, and a hobbyist photographer. I started in the 90s with my dad’s Minolta X-700, and when I first got my own camera it was a Nikon. I didn’t even consider Canon because the bayonet turned the “wrong” way! Stupid reason, but here I am decades later still using my FA, F100, D850 and others.

My uncle lent me his Hasselblad 500C for a while back then too, which I absolutely adored. I’d still love to have one, but my RZ67 was a lot cheaper. I also have a few large format cameras, which I just really enjoy using.

These days I mostly shoot hybrid and digital. I like mixing my own chemistry and experimenting with very old film. I have a bunch of 50 year old E-4 Ektachrome I’ve been playing with, for example. On the digital side, I also really like IR and full-spectrum.

I don’t consider myself much of an artist, I mostly just document life and tinker. I hate my job and would love to quit and start a camera repair shop or local darkroom co-op or something, but I’m too good at what I do and my employer won’t quit paying me too much 😜. Instead I try to stick to manageable small projects, like a custom data cable for my F100, fixing my old lenses, and other stuff like that. I have a handful of bigger projects in mind too but with all my other responsibilities I hesitate to commit to any of them.

Some day I should probably thin out my minor hoard of lenses and cameras.

Welcome!

Welcome aboard. It sounds to me like we could learn as much from you, as you could learn from us!

I'm a Minolta, RB67 & 4x5 user myself -- but today I have to tune-up my car.

Let me know if you have any luck with that haha. I'd love to be able to pull data from my F100 but it's been a nightmare trying to find software for it.

Yeah, it’s a little bit of a back burner thing but I think I found enough info on the interface to be able to write something simple if I can’t find any existing software. I’ll be sure to post something if I do get it going!

Hey from SLC, UT, wishing it was the central Cali coast.

I have spent the past decade sitting in a room surrounded by you DSP dorks. Half the time - no, 100% of the time - I can’t understand a single word. And could you and the CCA people get together and agree on what to call the pin functions for crying out loud? I don’t know FPGA or CCA, and let’s face it, barely understand English… I don’t need that kind of challenge.

Likewise, that includes cameras which focus the wrong way, so Nikon and Pentax it is. Even Leica bugs me. And let’s not even mention Plaubel or Voigtlander top knobs.

I also like tinkering with lenses. Nearly all of mine have been disassembled and, get this, reassembled the correct way. No kidding. A word of caution: don’t ever get into large format, and definitely don’t buy a Packard shutter. Suddenly every lens seems like a good deal/idea/project.

Anyhoo, welcome to the mostly-lurking corner of Photrio. Lots crossover in our Venn diagram. And if you could just update your packets to send zeros, or a pause frame, or whatever, that’d be great, mmmkay? Thanks.

I have spent the past decade sitting in a room surrounded by you DSP dorks. Half the time - no, 100% of the time - I can’t understand a single word.
As soon as you figure them out we make up new ones, it’s part of our job security strategy!

A word of caution: don’t ever get into large format, and definitely don’t buy a Packard shutter. Suddenly every lens seems like a good deal/idea/project.
Too late, I’m afraid. I have three 4x5 cameras and one of my current projects is to mount the lens cells from a Sekor Z 180mm lens in a Seiko #1 manual shutter - I hope to finish that one this weekend.
Welcome, PIC fiddler here!
Microcontroller gang rise up! I haven’t used PIC, but I’ve worked on a few AVR and ST7 systems. These days we mostly use STM32 and other ARM systems.

Thanks for the welcome, everyone :smile:

As soon as you figure them out we make up new ones, it’s part of our job security strategy!

You know, I was beginning to suspect so.


Too late, I’m afraid. I have three 4x5 cameras and one of my current projects is to mount the lens cells from a Sekor Z 180mm lens in a Seiko #1 manual shutter - I hope to finish that one this weekend.

Well, what’s done is done. It starts off all innocent with a #1, then before you know it you’re like, “Yeah, it’ll fit, but the weight is gonna be a problem. Maybe I could design a support and get someone to machine it for me…”. Good luck with that.

Let me know if you have any luck with that haha. I'd love to be able to pull data from my F100 but it's been a nightmare trying to find software for it.

And welcome :smile:

Yeah, it’s a little bit of a back burner thing but I think I found enough info on the interface to be able to write something simple if I can’t find any existing software. I’ll be sure to post something if I do get it going!


I can help with that. You probably need an Intel Windows XP VM. It sounds like you have the electrical interface part figured out, but I used the information from here to build mine:



There's third part software which has been made free, https://www.cocoon-creations.com/COCOON-NiCommSoftTALK-Download.shtml

You can also use Nikon's Photo Secretary which IIRC is findable by web search but if you have a hard time, let me know and I'll supply iso images.

I used a Nikon MC-21 data extension cable as a source for the connector, because it was the cheapest thing on eBay that had the correct connector, and a generic aliexpress ft232 breakout board for the usb-serial interface.

The only hitch for me was that the software will only use windows "COM1" or "COM2" interfaces to look for the camera, and by default the FT232 (via VM passthrough) shows up as COM5, so I had to mess with the XP device manager to rename the usb-serial device to COM1.

After all that, I'm able to reliably download exposure records from my F5 and fiddle with all the camera settings over the data cable. Note there are different versions of "Photo Secretary" for F100, F5, and maybe others, but they're all out there.

I can help with that. You probably need an Intel Windows XP VM. It sounds like you have the electrical interface part figured out, but I used the information from here to build mine:



There's third part software which has been made free, https://www.cocoon-creations.com/COCOON-NiCommSoftTALK-Download.shtml

You can also use Nikon's Photo Secretary which IIRC is findable by web search but if you have a hard time, let me know and I'll supply iso images.

I used a Nikon MC-21 data extension cable as a source for the connector, because it was the cheapest thing on eBay that had the correct connector, and a generic aliexpress ft232 breakout board for the usb-serial interface.

The only hitch for me was that the software will only use windows "COM1" or "COM2" interfaces to look for the camera, and by default the FT232 (via VM passthrough) shows up as COM5, so I had to mess with the XP device manager to rename the usb-serial device to COM1.

After all that, I'm able to reliably download exposure records from my F5 and fiddle with all the camera settings over the data cable. Note there are different versions of "Photo Secretary" for F100, F5, and maybe others, but they're all out there.


Why?

I'm not sure I understand the question. Why try to make a data interface to a camera?

Emily Cook and thinkbrown mentioned wanting to do it. You can shoot a roll of film and then download a file showing the lens and exposure data for each frame and various other things, and set some settings of the camera's behavior that can't be done on the camera, like tweaks to the autofocus behavior or metering.

Or was the "Why?" sarcastic and I missed some joke?

Maybe it was "why?" to the Windows XP VM. Either way, thanks for the info! I do have an XP VM for old vendor stuff like this already.

Depending on the complexity I may also attempt to throw together a simple open-source tool for the linux command line, since that's where I'm comfortable. For the electrical interface, I think I've got a simple workable plan - I found a few docs about it that tell me enough to build the actual cable itself. I was planning to maybe make a small hand-wired PCB with a USB-to-serial IC. I have the Nikon side of the cable already, in the form of a MC-30 cable release which I have verified has all the necessary wires inside, I just need to probe some things on my F100 to resolve some minor details that were ambiguous in the docs I've found so far, then probably order a few parts.

But first, playing with my discombobulated Mamiya 180mm lens - the manual shutter arrived today and it fits great, now I'm 3d printing a lens board and caps :smile:

Maybe it was "why?" to the Windows XP VM. Either way, thanks for the info! I do have an XP VM for old vendor stuff like this already.

Depending on the complexity I may also attempt to throw together a simple open-source tool for the linux command line, since that's where I'm comfortable. For the electrical interface, I think I've got a simple workable plan - I found a few docs about it that tell me enough to build the actual cable itself. I was planning to maybe make a small hand-wired PCB with a USB-to-serial IC. I have the Nikon side of the cable already, in the form of a MC-30 cable release which I have verified has all the necessary wires inside, I just need to probe some things on my F100 to resolve some minor details that were ambiguous in the docs I've found so far, then probably order a few parts.

But first, playing with my discombobulated Mamiya 180mm lens - the manual shutter arrived today and it fits great, now I'm 3d printing a lens board and caps :smile:

Oh, it's just that the old software for it only runs under XP. I'd definitely prefer a CLI interface too and if you get something together I'd love to play with it! That would really be ideal. I don't think it's that complex an interaction with the camera but it's sure not my forte. For what it's worth I can at least confirm that it only needs TXD, RXD, and ground, and it's 5v signalling. Anyway welcome!
