Good info on using flash bulbs.

StepheKoontz

Member
Joined
Dec 4, 2018
Messages
801
Location
Doraville
Format
Medium Format
Got a fan type BC flash with a tower rangefinder and some P25 bulbs. Got a battery and a new capacitor on the way and trying to find a source of info on guide numbers etc to play around with this. TIA


BAC1967

Subscriber
Joined
Oct 30, 2014
Messages
1,433
Location
Bothell, WA
Format
Medium Format
I assume you don’t have the box, it’s usually in a table on the back of the box. I can check if I have it on one of my boxes.

OP
OP

StepheKoontz

Member
Joined
Dec 4, 2018
Messages
801
Location
Doraville
Format
Medium Format
BAC1967 said:
I assume you don’t have the box, it’s usually in a table on the back of the box. I can check if I have it on one of my boxes.
Click to expand...

The instructions I have just list films like "kodachrome, anscochrome, ektachrome, kodacolor" etc. I wasn't sure if there was a website I was missing that talks about using flash bulbs I wasn't finding. This looks like it could be fun!


BAC1967

Subscriber
Joined
Oct 30, 2014
Messages
1,433
Location
Bothell, WA
Format
Medium Format
StepheKoontz said:
Thanks!!! And from these guide numbers, that's an insane amount of light!
Click to expand...
They do put out a lot of light, if you're taking pictures of people they will complain about loosing their vision but it's usually only temporary. I have done some bracketing tests by placing markers at different distances with the distance and f-stop marked on them. I also included a test patters with a range of colors. That allowed me to make a cheat sheet that I taped to the flash. I did this for my View-Master camera since it has a dedicated flash and there's only one shutter speed that works with the flash. I just guess the distance and set the aperture, works great.


MattKing

Moderator
Moderator
Joined
Apr 24, 2005
Messages
52,918
Location
Delta, BC Canada
Format
Medium Format
Be careful when using old flashbulb data that references ASA or old films.
The ASA standard was revised in 1960 - essentially doubling the number for most films.
As Kodachrome II came out in 1961, you are probably safe using the film speeds on that first box.
And yes, they give out a lot of light. That is why you can find lots of flash pictures on ASA 10 Kodachrome!


voceumana

Member
Joined
Aug 4, 2004
Messages
896
Location
USA (Utah)
Format
Multi Format
FYI, clear flash bulbs are for black and white and tungsten color films; blue flash bulbs are for daylight color films and can be used for black and white. Tungsten color films are not around much today (if any) as electronic flash is color balanced for daylight films.

As to the amount of light, it is quite intense. Probably one reason that in the 1960's the AG1 bulb (the size of a lima bean) became popular--its the size bulb used in the first flash cubes.

OP
OP

StepheKoontz

Member
Joined
Dec 4, 2018
Messages
801
Location
Doraville
Format
Medium Format
MattKing said:
Be careful when using old flashbulb data that references ASA or old films.
The ASA standard was revised in 1960 - essentially doubling the number for most films.
Click to expand...

Good info. Sounds like there might be some trial and error testing in order. I also want to see if the "quality" of light is different. I'm thinking with this flash unit I have with a fairly flat reflector that the light will be more omni directional than a strobe?


Kodachromeguy

Subscriber
Joined
Nov 3, 2016
Messages
2,054
Location
Olympia, Washington
Format
Multi Format
Another hint: if you are indoors in a room with white ceiling and reasonably neutral walls, try using bulbs without the reflector. You will get a lot of reflection from the ceiling and walls, and the light will not look as directional (unless you specifically want that look).


GRHazelton

Subscriber
Joined
May 26, 2006
Messages
2,248
Location
Jonesboro, G
Format
Multi Format
I well remember the bulb days! In the late 50's I shot for my high school newspaper, using IIRC M 3 bulbs in a flash gun by Kodak that held 5 or 6 bulbs in a plastic circular "magazine" which fit into a battery capacitor gun on a bracket attached to the camera's tripod socket. This let me shoot pretty fast with my leafshutter 35mm rangefinder. Shooting football I'd try to anticipate the action, prefocus, and wait. Same sort of thing with basketball. Four or five keepers per football game was a good eening! The power of the flash let me use smallish apertures on Plus X rated to about ASA 300, souped in Beutler. When automatic electronic flashes arrived at an affordable price it was wonderful!


Sirius Glass

Subscriber
Joined
Jan 18, 2007
Messages
50,364
Location
Southern California
Format
Multi Format
With ISO numbers.


AndyH

Member
Joined
Aug 16, 2004
Messages
451
Location
New England
Format
Medium Format
If you plan to shoot with bulbs, I can't give a better recommendation than the Kodak Master Photoguide. Calculators, tables, and a whole lot more. You can find one cheap on the 'Bay or at major online dealers.

Andy


mgb74

Subscriber
Joined
Jan 24, 2005
Messages
4,774
Location
MN and MA US
Format
Multi Format
I'm curious - wouldn't the size and shape of the reflector have an impact on GN? And, with older equipment, the condition?


BrianShaw

Member
Joined
Nov 30, 2005
Messages
16,526
Location
La-la-land
Format
Multi Format
Some GN tables have different values for different reflector types.


Dirb9

Member
Joined
Mar 19, 2006
Messages
153
Format
Multi Format
Size, shape, and even finish of the reflector will have an effect on the GN; the 1977 kodak guide has guide numbers for "polished bowl", "intermediate" and "shallow cylindrical" reflectors. Bill Cress' site lists different GN tables for different style reflectors as well: https://web.archive.org/web/20180519103715/http://www.flashbulbs.com/ClearBulbs.htm . An old Westinghouse #11 bulb box I have states "increase exposure 1/2 stop for satin-finish type reflector"


BrianShaw

Member
Joined
Nov 30, 2005
Messages
16,526
Location
La-la-land
Format
Multi Format
... and as long as we’re discussing the myriad considerations that are important to consider when using flashbulbs, don’t forget the effect of shutter speed on GN. It can be significant!

see in posts 3 and 6, and the right side table in post #14.

OP
OP

StepheKoontz

Member
Joined
Dec 4, 2018
Messages
801
Location
Doraville
Format
Medium Format


Thanks for the link. Here is a shot of the flash unit I am rebuilding for this project. I found the correct battery and am going to replace the capacitor, should work great It works with both P25 and M3 type bulbs.
