MattKing

Moderator
Moderator
Joined
Apr 24, 2005
Messages
52,927
Location
Delta, BC Canada
Format
Medium Format
You might even have success with just a tray of water at the bottom of the dryer.
If you can put something protective over top that still allows airflow, it can help avoid the inconvenience that occurs when the film slips and drops.


eli griggs

Member
Joined
Nov 15, 2005
Messages
3,847
Location
NC
Format
Multi Format
For sometime now, I've been using an inexpensive suit carrying bag as a film drying cabinet.

The bottom panel is cut to fit a card and fiberglass type air filter like used in AC's and in Central Heating and Air intakes, mounted inside the unit.

A small fan/heater set on low heat sits underneath the ceiling mounted cloths bag, on the outside, and a second filter, mounted into and inside the top of the bag keeps dust out or collected from whatever floaters make it up that far, by the convection of heated air.

The cloths hangers rack is supported by additional support lines that allow more lines of film/sheet film to be hung.

Velcro straps allows me to raise up the bottom and middle up to the top of the unit for in place storage and keeps it from hanging down and taking up space when no one use.

It's an easy-peasy, low cost set up that can travel, if needed and only occupies a bit of celling space 🌌 until wanted.

If I wanted, I could also prep the hanging space by using my small travel steamer to run steam up from bellows outside the bag, into the filtered drying space, like clearing dust out of the air in a shower, before hanging negatives.

It's simple, low cost and does a good job when used.

Cheers to all and Godspeed,
Eli
