Can I mask a 6x6 negative carrier to 6x4.5? How so?

Recent Classifieds

Forum statistics

Threads
177,038
Messages
2,428,551
Members
94,115
Latest member
odeo606
Recent bookmarks
0

Markok765

Member
Joined
Apr 26, 2006
Messages
2,263
Location
Ontario, Can
Shooter
Medium Format
Hey guys!

I want to print 645 and my school only has 6x6 negative carriers. whats the best/easiest way to mask it to work?


MattKing

Moderator
Moderator
Joined
Apr 24, 2005
Messages
37,782
Location
Delta, BC, Canada
Shooter
Multi Format
Is the negative part of a strip of negatives? If so, you probably don't need to worry about it - just crop using the easel.

What type of enlarger and negative stage are you using?

OP
OP
Markok765

Markok765

Member
Joined
Apr 26, 2006
Messages
2,263
Location
Ontario, Can
Shooter
Medium Format
Not sure what type/negative stage.. It's a 4x5 enlarger however.

hmm you're right about the easel idea. seems the simplest solutions are the best!


wiltw

Subscriber
Joined
Oct 4, 2008
Messages
5,101
Location
SF Bay area
Shooter
Multi Format
You always can take a simple file folder, and trim out a 645 space to serve as a mask to block stray light which might reduce contrast. Then cut down the outer part of the file folder and punch out round holes where the metal pins of the 6x6 carrier would protrude through the file folder. And black out the file folder with black felt marker to cut light transmission to minimums.

I had a 6x6 enlarger as a kid, and did exactly what I described to make a 135 format mask...not enough money in the budget of a 14 year old to buy a 135 format neg carrier!


Bob Marvin

Member
Joined
Sep 7, 2002
Messages
114
Location
Brooklyn, NY
Shooter
Medium Format
FWIW I use a 6 X 6 carrier for my 6 X 4.5 negatives without any masking. It's no worse than cropping a 6 X 6 negative to make a vertical or horizontal print.


dorff

Member
Joined
May 31, 2011
Messages
443
Location
South Africa
Shooter
Multi Format
Yes you can use the 6x6 but if for some reason that shines too much extraneous light, black matte board works great for custom neg carriers.

Yes, that will work well. Another possibility is to use a 6x6 frame of fully exposed and developed film, and to cut the 6x4.5 window out, then sandwich that with your negative. Do the final cropping with the easel.

Joined
Sep 10, 2002
Messages
2,734
Location
Eugene, Oregon
Shooter
4x5 Format
Just crop on easel.

Your baseboard and easel should be yellow, red or black, which will not reflect any light that your photo paper is sensitive to. I crop 4x5 negs down quite a bit when needed and never have felt the need for masking the negative.

Now, if you have bright white baseboard and easel, you might want to consider it...

Best,

Doremus


RalphLambrecht

Subscriber
Joined
Sep 19, 2003
Messages
12,877
Location
K,Germany
Shooter
Medium Format
Hey guys!

I want to print 645 and my school only has 6x6 negative carriers. whats the best/easiest way to mask it to work?



I was lucky enough to find thin black plastic sheets; only 1mm thick and flat black,which I used to cut myself several masks for my L1200 negative carrier; worked great, but I don't remember where I got the material;it can be easily cut with a carpet knifeinto any shape; also great for making custom dodging tools.


DannL.

Member
Joined
Oct 13, 2013
Messages
617
Shooter
Large Format
Mat board is a fine material for making a simple negative carrier, if you desire. The example pictured here is one designed from scratch for use in a Leitz Valoy enlarger.

View attachment 77186 View attachment 77187

Last edited by a moderator:

fotch

Member
Joined
Mar 16, 2005
Messages
4,774
Location
SE WI- USA
Shooter
Multi Format
I would not worry about it. If you shoot this format often, you can eventually pick up a used one at a good price.


MattKing

Moderator
Moderator
Joined
Apr 24, 2005
Messages
37,782
Location
Delta, BC, Canada
Shooter
Multi Format
I would not worry about it. If you shoot this format often, you can eventually pick up a used one at a good price.

Which is one of the reasons I asked what type of enlarger it was for :smile:.
