jseffel

Member
Joined
Dec 26, 2010
Messages
16
Format
35mm
I shot a roll and 6 out of 36 images had these strange light leaks / flares - other images with faster and slower shutter speeds looked find. The lens seems clean, I've had the camera over a light table to see if there might be a hole in the shutter (Leica M2) but I did not see anything. Has anyone seen this before?


Attachments

  • 20220906-_MG_1629.jpg
    896.4 KB · Views: 86
  • 20220906-_MG_1630.jpg
    797.2 KB · Views: 87
  • 20220906-_MG_1634.jpg
    727.3 KB · Views: 95

xkaes

Subscriber
Joined
Mar 25, 2006
Messages
4,791
Location
Colorado
Format
Multi Format
Since the "stuff" appears the same in two very different scenes, it's not something in the scene -- like reflections.

If it is the lens, it should show up in all of the images.

I'm not familiar with the shutter on the M2. If it is a horizontal cloth shutter, it has TWO flaps, and the problem could be in either of them (opening or closing).

If you can't visually see any problem in the shutter, I'd run a test roll against a grey card or mid-tone wall -- with the camera on a tripod. Use the same lens, and take exposures at each shutter speed and see if it only shows up at certain speeds.


snusmumriken

Subscriber
Joined
Jul 22, 2021
Messages
2,505
Location
Salisbury, UK
Format
35mm
I shot a roll and 6 out of 36 images had these strange light leaks / flares - other images with faster and slower shutter speeds looked find. The lens seems clean, I've had the camera over a light table to see if there might be a hole in the shutter (Leica M2) but I did not see anything. Has anyone seen this before?
Did you examine the shutter both before and after winding on?


henryvk

Member
Joined
Feb 14, 2021
Messages
380
Location
Europe
Format
Medium Format

Alan9940

Member
Joined
Jun 17, 2006
Messages
2,424
Location
Arizona
Format
Multi Format
I, too, suspect the shutter. In addition to all the good suggestions above, I'd try the light table thing, again, and fire the shutter several times to see if anything changes between firings. Could be the shutter is messing up intermittently. Make sure all light around the camera is covered to ensure you're seeing only light coming through the shutter. And I'd recommend doing this in a very dark room.

OP
OP

jseffel

Member
Joined
Dec 26, 2010
Messages
16
Format
35mm
It was the shutter. I noticed it when I sat in a pitch black closet. The holes are tiiiiiny.

Thanks!


cramej

Member
Joined
Dec 29, 2009
Messages
1,235
Format
Multi Format
Black fabric paint will take care of this until you decide to have the curtains replaced. Use sparingly, follow the instructions, check with a bright light as you work.


ic-racer

Member
Joined
Feb 25, 2007
Messages
16,548
Location
USA
Format
Multi Format
I’ll put a vote on shutter curtain.
I started a thread on shutter curtain speed testing and timing in anticipation of doing curtain replacement, but as of yet, have not replaced any.


Huss

Member
Joined
Feb 11, 2016
Messages
9,058
Location
Hermosa Beach, CA
Format
Multi Format
Upside is this was very easy to diagnose, and the repair can be easy. Either 'paint' over the pinholes with carbon black paint:


or get the shutter curtains replaced. I've used the paint on a Zenit and it worked great. Thing is, your M2 is obviously old, and so it may need new curtains anyway. yyecamera.com charges $185 to replace them.
