Website Resources - Scanning

In flight......

A
In flight......

  • 3
  • 0
  • 78
Ephemeral Legacy

A
Ephemeral Legacy

  • 3
  • 0
  • 61

Forum statistics

Threads
200,744
Messages
2,813,276
Members
100,362
Latest member
Gert Jan
Recent bookmarks
1

jd callow

Moderator
Moderator
Joined
Jan 31, 2003
Messages
8,466
Location
Milan
Format
Multi Format
Thank you for starting this thread. I will be adding a resource section for links of this kind and would appreciate it if everyone would use this thread as a repository for their favorite scan links.


MAGNAchrom

Member
Joined
Jul 17, 2006
Messages
132
Location
Massachusett
Format
Multi Format
LOL: and if you want to see what was "state of the art" back in 1995, you can still download my old Scanning Tips at:

Dead Link Removed

(WARNING: this puppy is BIG -- don't try this with dialup)

This is a PDF version of my book "Make Your Scanner a Great Design & Production Tool" now long since remaindered. It was the first layman's book on using a flatbed scanner. And while the equipment is waaay old, much of the book is still valid. Funny to look back at how things once were...


pellicle

Member
Joined
May 25, 2006
Messages
1,175
Location
Finland
Format
4x5 Format
Joined
Jul 13, 2006
Messages
266
Location
Europe
Format
Multi Format
Some links to professional scan studios:

http://www.scanguru.info

If you should happen to know other studios, please add the studio in the form and submit it - it'll help us all!


GerardK

Member
Joined
Jun 27, 2006
Messages
14
Location
Netherlands
Format
4x5 Format
I hope I'm not breaking any forum rules here, but I've published a scanning guide on Amazon CreateSpace that you may find useful:

Dead Link Removed

It's a workflow that I've developed over hundreds of hours of scanning. I was looking for a way to scan color transparencies and negatives just once, without interpreting the image data during scanning, while retaining all shadow and highlight information. This step-by-step workflow description is richly illustrated with screenshots, and should be easy to follow. It also contains a basic introduction to color management in scanning. The method requires a desktop flatbed or film scanner, Photoshop CS or later, VueScan or Silverfast, and the Photoshop plug-in ColorPerfect.
Best regards, Gerard Kingma


GerardK

Member
Joined
Jun 27, 2006
Messages
14
Location
Netherlands
Format
4x5 Format
ColorPerfect and B/W


Since I published 'The Illustrated Guide to to Film Scanning', a number of people have asked me if the method would work for B/W. So I went into the attic and dug up and old roll of Kodak Tmax that I'd tortured through a battered Rolleiflex many years ago. It's poorly exposed (this particular frame is underexposed) and questionably developed, but hey, there it is.

The scanning method I advocate in the guide, is based on the assumption that it doesn't really matter what the chemical contents are of the particular piece of celluloid that you feed your scanner. You make a kind of snapshot of the film, correct it for scanner behavior with a dedicated IT8 calibration, make a linear file and process that in ColorPerfect. So for this B/W, I followed the exact same procedure as for negative film described in the guide. The only difference is, digital ICE doesn't work with B/W, but I suppose B/W photographers know this already. In the color workflow, I converted from the scanner profile to ProPhotoRGB, to work in the largest possible workspace. After that I simply changed the mode to Greyscale and there you are, you've got a 16bit B/W file that contains all highlight and shadow information that's present in the film. By definition it's therefore rather bland, see the unprocessed file above, but you now can (and should) apply your usual Photoshop skullduggery to taste, to make the image come to life. I will leave that to the true B/W photographers among you. I really appreciate a good B/W, but it's just never become my thing.

Once more, here's the link to the guide on Amazon:

The Illustrated Guide to Film Scanning: A best-practice guide to scanning negatives and transparencies: Gerard Kingma: 9781484137437: Amazon.com: Books

Please post your own experiences here. I will try to help out where I can.

Best regards, Gerard Kingma


GerardK

Member
Joined
Jun 27, 2006
Messages
14
Location
Netherlands
Format
4x5 Format
