Format
Medium Format
Hi
I get those strange 3 lines on some of my photos (sometimes you can see them and sometimes not, on the same roll).
can someone help me with that?
I saw people writing about lines on their hasssy photos but those look different from the one that are shown in the forum.
I think that the lines are on the side of the pinning mechanism that holds the film.
thnx


Attachments

  • Eilat_2012_2.jpg
    58.1 KB · Views: 425
  • Eilat_2012_4.jpg
    58.2 KB · Views: 356
  • Eilat_2012_21.jpg
    70 KB · Views: 324

karl

Member
Joined
Jan 17, 2003
Messages
224
Location
SanFrancisco
Format
ULarge Format
Time for new light seals in the film back. It's fairly easy to do yourself.


K-G

Subscriber
Joined
Mar 29, 2006
Messages
550
Location
Goth, Sweden
Format
Multi Format
Time for new light seals in the film back. It's fairly easy to do yourself.

Light leakage due to defective light seals use to look completely different. The light traces normaly go sideways, not between top and bottom.

Karl-Gustaf

OP
OP

slonimator

Member
Joined
Oct 9, 2012
Messages
2
Format
Medium Format
Thnx
you are right
I have the same problem with my v750 (I'm so f***) :sad:


rawhead

Member
Joined
Jun 18, 2009
Messages
588
Location
Boston, MA
Format
Medium Format
Thnx
you are right
I have the same problem with my v750 (I'm so f***) :sad:


One trick I learned through this whole snafu; when you have a shot like yours (and mine on my Flickr site), where you have a neg that is dense on top and thin on bottom––i.e., something like sunny sky on top and ground surface on the bottom, this problem is greatly reduced (sometimes to zero) by rotating your negative 180˚, so that the scan head hits the ground part first and the sky part next. From my understanding, it's the strong contrast between the edge of the dense part of the negative and the translucent part just outside the frame, that causes this banding. The problem is magnified it you use a film (like the Acros 100 I used) that tend to go entire clear during fix. Yeah it's ugly, but waddayagonna do?

Unless, of course, this new Plustek film scanner is good enough that I'd want to shell out 2000 clams to upgrade from my V700 :smile:


Andrew Moxom

Member
Joined
Feb 2, 2007
Messages
4,888
Location
Keeping the
Format
Multi Format
This is amvery common problem on the Epson 700 and 750 scanners. They are reflections bouncing around due to the multiple layers of glass. One way to allevite them is to tape the negs emulsion side down to the lower platen with thin hinging tape. I lay my negs down and tape one edge down, then i place a strip of tape on the opposite edge film rebate, and stretch it out and down onto the platen. Then change your scanner silverfast software to scan the Full film area with the little frame overlay they supply, and go from there. Its a way to get the best results i have managed with this scanner short of a better scanning film holder, even then reflections can still cause issues.


Philippe-Georges

Subscriber
Joined
Apr 11, 2005
Messages
2,672
Location
Flanders Fields
Format
Medium Format
The first neg. is left—right reversed, the Hasselblad frame marks should be on the left side. Perhaps you scanned emulsion up?
Then the remark by Andrew of bouncing reflexions is valuable here too?

Joined
Jan 21, 2003
Messages
15,708
Location
Switzerland
Format
Multi Format
This is amvery common problem on the Epson 700 and 750 scanners. They are reflections bouncing around due to the multiple layers of glass. One way to allevite them is to tape the negs emulsion side down to the lower platen with thin hinging tape. I lay my negs down and tape one edge down, then i place a strip of tape on the opposite edge film rebate, and stretch it out and down onto the platen. Then change your scanner silverfast software to scan the Full film area with the little frame overlay they supply, and go from there. Its a way to get the best results i have managed with this scanner short of a better scanning film holder, even then reflections can still cause issues.

Yep. What Andrew says works beautifully, and eliminates these problems for the most part. It's very annoying to spend hundreds of dollars on a piece of equipment that does this. I have noticed the following, in addition to what Andrew mentions:
1. 'Shiny' emulsions, like TMax 100 and TMax 400 are far worse than something like Ilford FP4+. It's as though the emulsion side has the same glossy sheen as the film base side on these films, which makes sense they'd perform worse, since they would be another reflective surface.
2. This happens with 35mm film as well. It is not isolated to 120 film. I just don't think the Epson V700/750 scanners are very well constructed machines for this reason.
3. I've had it happen with C41 color film as well. Portra 400 among others.

Obviously, taping negatives to the scanner platen is a pain in the back side compared to using the film holders, especially if you have many negatives to scan. But it does work.

Joined
Oct 1, 2011
Messages
171
Location
DeLand Flori
Format
Multi Format
I was getting the same thing from my Canon scanner (8800F) until I bought an ANR glass insert and negative holder. The glass has a matte side that goes next to the negative holding it flat on the scanner. This eliminated the lines and other reflections. It also sharpened up the images because the negative is now flat and on the glass, not slightly above it like in the Canon film holder.
