Pinhole cameras haves a natural vignetting feature to them. The exposer looks fine but starts to fade towards the edge of the picture.

Using my 4x5 view camera, I can adjust the bellows to give me an aperture between f180 and f500 with a .016" pinhole. However, I seem that when I get above f250 or f360 I start getting a dark spot forming in the center of the negative.

I am not sure if this is diffraction, or a slight light leak or light reflecting off the bellows interior but it only seems to be an issue with long exposures over 3 minutes or so.

Has any one else noticed this phenomenon with longer exposures.


Sirius Glass

Subscriber
Joined
Jan 18, 2007
Messages
50,219
Location
Southern California
Format
Multi Format
Please post and example.

OP
OP

Grandpa Ron

Member
Joined
Sep 4, 2018
Messages
112
Location
Northwest Indiana
Format
35mm
Here are some examples of what I am talking about.

4x5 trees, the bright spot is not the sun behind the trees

4x5 trees .jpg


The 4x5 privy is shot with me and the white privy in the deep shadows . The exposure captured the background very well. Once again you can see the bright spot.
4x5 Privy.jpg

The 4x5 swing image was vignette by my pin hole and shutter mounting method. The bright spot appears on the swing arm on the right.
4x5 swing.jpeg


Finally I have several 35mm shots when I used a black cardboard tube to place the pinhole farther from the film plane. This is a underexposed shot but you can see the bright spot.
35mm bridge .jpg


I believe I have some sort of reflection bouncing around the 4x5 bellows and the 35mm black cardboard tube. This bright spot appears to some degree in almost all my pinhole shots. My pin holes range from .014" to .025" and the 4x5 shots were with and aperture of f357. I usually shoot on sunny days to reduce the exposure time.

At this point any suggestion would be helpful.


RalphLambrecht

Subscriber
Joined
Sep 19, 2003
Messages
14,600
Location
K,Germany
Format
Medium Format
Here are some examples of what I am talking about.

4x5 trees, the bright spot is not the sun behind the trees

View attachment 232220

The 4x5 privy is shot with me and the white privy in the deep shadows . The exposure captured the background very well. Once again you can see the bright spot.
View attachment 232221
The 4x5 swing image was vignette by my pin hole and shutter mounting method. The bright spot appears on the swing arm on the right.
View attachment 232222

Finally I have several 35mm shots when I used a black cardboard tube to place the pinhole farther from the film plane. This is a underexposed shot but you can see the bright spot.
View attachment 232223

I believe I have some sort of reflection bouncing around the 4x5 bellows and the 35mm black cardboard tube. This bright spot appears to some degree in almost all my pinhole shots. My pin holes range from .014" to .025" and the 4x5 shots were with and aperture of f357. I usually shoot on sunny days to reduce the exposure time.

At this point any suggestion would be helpful.
reflection from the sun would be my guess too.


AgX

Member
Joined
Apr 5, 2007
Messages
29,973
Location
Germany
Format
Multi Format
In the photograph of the little hut the sun is on the right hand side above. I hardly think the sun could produce an image at that location.


wyofilm

Member
Joined
Nov 12, 2017
Messages
1,158
Location
Wyoming
Format
Multi Format
What is covering your pinhole when not taking the image? Is it possible that the tape (or whatever you are using) isn't fully light tight?
