Hi

I just want to present my new pinhole camera, The ModaPin!
It's an old Kodak Brownie with the lens and the shutter removed.
I have covered all holes (except the pinhole :smile:) with duct tape and made a pinhole in tin foil with a syringe (i have 0.4, 0.6, 0.8 and 1.2 mm. pinholes made already).
I think a lot of others has done this too with old box cams, so I don't think I'm original :smile:

I have shot a few rolls of FP4 and I'm fine tuning the exposure.
A picture will be on this thread soon.

Morten


clogz

Subscriber
Joined
Dec 28, 2002
Messages
2,383
Location
Rotterdam, T
Format
Multi Format
Hello Morten. Good idea. Let me know the results of your experiment with FP4
Hans

OP
OP
modafoto

modafoto

Subscriber
Joined
Oct 17, 2003
Messages
2,101
Location
Århus, Denmark
Format
35mm
Here are three pics from the ModaPin.


Attachments

  • modapin-baghave.jpg
    36.5 KB · Views: 232
  • modapin-selfportrait.jpg
    54.5 KB · Views: 235
  • modapin-fortov2.jpg
    92.9 KB · Views: 211

phototech

Member
Joined
Jan 27, 2005
Messages
3
Format
Multi Format
I too have modified the old box cameras like the Kodak #2. Love the 120-6x9 format for great pin-panos. I leave the shutters in place, as I find it much easer to deal with than tape, and the box cameras offer built-in view finders.


jimgalli

Subscriber
Joined
Sep 7, 2002
Messages
4,232
Location
Tonopah Neva
Format
ULarge Format
I'm forever robbing shutters out of old Polaroid Oscilloscope cameras. That leaves the 3.25 X 4.25 Polaroid packfilm holder and usually the remains of the camera sticking 3 1/2 inches in front. All you have to do is make a black matboard cover and a place to tape a foil pinhole on. 3X4 is a great pinhole size and it's instant (as instant as possible with a pin hole) gratification with the polaroid 108 or 667 films. If I use 665 I have a positive to look at and a negative that can go in the enlarger. Here's a couple of pics done that way. I enlarged the Tonopah Nev. Coke bottle bottom to 10X12 on 11X14 paper.
