I developed a few rolls of Ilford FP4+ film today and experienced something I have never seen before. There is a faint imprint of the numbers on the back side of the paper backing on the developed film. It is fairly faint, but at the same time there is a kind of paper texture over all of the film, but most visible in the areas of low density.

Has anyone ever seen anything like this? How could it happen? The paper backing must be light tight so I don't see how the imprint could be caused by fogging, and there was none in any event because except for the imprint the negatives appear to be very well exposed and developed, with a very low B+F.

Sandy


jim appleyard

Subscriber
Joined
Nov 21, 2004
Messages
2,413
Format
Multi Format
Sandy, there's a similar question on photo.net. You may want to check it out.


glbeas

Member
Joined
Sep 25, 2002
Messages
3,912
Location
Marietta, Ga. USA
Format
Multi Format
From my experience in the printing industry I would guess the paper backing may have been rushed through its production and the imprint is caused by "ghosting" or a vapor imprint from the solvents in the inks used to cover the paper. It may well be that excess solvent also had an effect on the film itself too, penetrating into the film and changing its permeability to water.

Joined
Aug 16, 2003
Messages
141
Location
sao paulo -
Format
4x5 Format
It happened with me some years ago (FP4 also) . Ilford answered it was some problem with back paper used. I've seen some others complaining about that during recent years. It means, unfortunately, that Ilford was not able to solve this until now ( poor quality control ). It will be good, at least, to email Ilford about that.


oriecat

Member
Joined
Nov 4, 2004
Messages
241
Location
Portland, OR
Format
35mm
I've had it happen to me! Both rolls of Fuji I shot in San Francisco back in August didn't roll tight, one totally didn't even come out and the other had tons of paper imprinted all over it. I figured it happened because of the improper rolling allowing light to expose through somehow.

Examples:


Attachments

  • sf1.jpg
    15.4 KB · Views: 156
  • sf3.jpg
    20.9 KB · Views: 176

rjr

Member
Joined
Aug 30, 2004
Messages
406
Location
Mosel, SW Ge
Format
Medium Format
Sandy,

it is a known problem with many film brands. According to Matthias Schneege, a german Ilford rep it usually happens with outdated -read: long stored- film and it is a reaction of the emulsion with the ink used in printing.

Odd enough, Ilford uses only a very faint printing on their backing papers, impossible to use with old "red window" folders... :-(


jim appleyard

Subscriber
Joined
Nov 21, 2004
Messages
2,413
Format
Multi Format
If that URL doesn't work, the question was posted by Larry Yungk, Dec. 5, '04 and was titled, "Numbers Burned Into Efke Film". I found it under the catagory of "beginner questions".


jandc

Member
Joined
Jan 29, 2004
Messages
601
sanking said:
I developed a few rolls of Ilford FP4+ film today and experienced something I have never seen before. There is a faint imprint of the numbers on the back side of the paper backing on the developed film. It is fairly faint, but at the same time there is a kind of paper texture over all of the film, but most visible in the areas of low density.

Has anyone ever seen anything like this? How could it happen? The paper backing must be light tight so I don't see how the imprint could be caused by fogging, and there was none in any event because except for the imprint the negatives appear to be very well exposed and developed, with a very low B+F.

Sandy

There are two ways this happens. One is light burn through when the opaque paper backing is weak. Of course this only happens if you have an old camera with a red window. The other possibility, which is more common, is bleed through. This is a chemical reaction as indicated above. Usually the manufacturers pick up on the flaw and do not ship out these films. However we've heard of this several times in the last year with several brands including Ilford.

The Efke problem on the Photo.net post was light leak through on a red window camera due to a weak backing.

Joined
Sep 7, 2002
Messages
594
Location
Sacramento
Format
Medium Format
I once heard some speculation that this could also be caused by x-ray fogging from airports. I was wondering if this is possibly another avenue for the printing to be marking the film?

My thinking is that it is not the case, because unless the ink has properties that are reflective or absorptive to x-rays, the ink areas would look exactly the same as the paper areas on the film. While I suppose it is possible that the ink has a distinctive X-ray characteristic, I would think that the manufacturers would avoid this if at all possible...

Anyone know if there is any truth to x-ray fogging of this manner?


---Michael


ThomHarrop

Member
Joined
Dec 24, 2003
Messages
172
Location
Denver, CO
Format
4x5 Format
<There is a faint imprint of the numbers on the back side of the paper backing on the developed film.
Has anyone ever seen anything like this? How could it happen?>

My students and I do a LOT of Holga work. It is not uncommon to see it with Holga. I usually just means the camera has a light leak. You might think about having your camera seals checked.

OP
OP

sanking

Member
Joined
Mar 26, 2003
Messages
5,437
Location
Greenville,
Format
Large Format
ThomHarrop said:
<There is a faint imprint of the numbers on the back side of the paper backing on the developed film.
Has anyone ever seen anything like this? How could it happen?>

My students and I do a LOT of Holga work. It is not uncommon to see it with Holga. I usually just means the camera has a light leak. You might think about having your camera seals checked.

A light leak is the first thought that crossed my mind but for various reasons I have pretty much eliminated this possibility. For one thing the camera is a late model Fuji GS690III that I have used for several years with never a hint of any kind of fogging. And, of some fifteen rolls of film that I developed taken with this camera durung this particular session only two rolls had the problem, and both were Ilford FP4+. Thirteen other rolls, including nine rolls of the faster HP5+, showed no signs at all of a light leak.

Sandy
